Description

The YP1000cc injector is a high impedance,“saturated” injector. Suitable for most fuel injected engines.

Specifications

Motec | 34015 | Injectors

Electrical

  • Impedance 12 Ω
  • Maximum power supply 16 V

Physical

  • Operating temperature range -40 to 110 °C
  • System pressure maximum 8 bar
  • Weight 25 g
  • EV6 style connector
  • Flow rate 1015 cc/min @ 3 bar, 100% duty on VP C16 fuel at 52 °C (125 °F)
  • 14 mm top O-Ring
  • Fuel rail bore size 13.89 mm (0.547")

Compatibility

  • All MoTeC ECUs

Compatibility

  • Universal Part

The YP1000cc injector is a high impedance,“saturated” injector. Suitable for most fuel injected engines.

Motec | 34015 | Injectors

Electrical

  • Impedance 12 Ω
  • Maximum power supply 16 V

Physical

  • Operating temperature range -40 to 110 °C
  • System pressure maximum 8 bar
  • Weight 25 g
  • EV6 style connector
  • Flow rate 1015 cc/min @ 3 bar, 100% duty on VP C16 fuel at 52 °C (125 °F)
  • 14 mm top O-Ring
  • Fuel rail bore size 13.89 mm (0.547")

Compatibility

  • All MoTeC ECUs
  • Universal Part
