Description

Built for performance and show, the 69 Series Typhoon™ Air Intake System is a free-flowing mandrel-bent aluminum tube induction system designed to fit many sport compact performance vehicles. Typhoon intake tubes have a high quality finish that's made to last. K&N intake systems replace your vehicle's restrictive factory air filter and air intake housing. K&N intakes are designed to dramatically reduce intake restriction resulting in additional power and torque. All of them come with K&N's Million Mile Limited Warranty and are guaranteed to increase horsepower. Some Typhoon Air Intakes are not legal for use in California and other states adopting California emission standards while others are CARB exempt and 50 state legal. Check the K&N catalog or website vehicle parts search for specific CARB status.



  • Will boost horsepower
  • Designed to improve throttle response and engine sound
  • Free-flowing aluminum tube
  • Replaces entire factory air intake system
  • Lasts up to 100,000 miles before service is required (depending on driving conditions)
  • Easy to install, usually in 90 minutes or less
  • Washable and reusable lifetime air filter
  • K&N Million Mile Limited Warranty®

Specifications

  • Product Style: 69 Series Typhoon Kits
  • Estimated Horsepower Gain: 25.68 HP @ 4300 RPM
  • Replacement Filter: RU-4960
  • Air Filter Color: Red
  • Air Filter Outlet Shape: Round
  • Street Legal In All US States: Yes
  • Air Filter Height: 5.5 in (140 mm)
  • TUV Approved (Europe): No
  • Air Filter Material: Cotton Gauze
  • Clamps Included: 3
  • Clamp Material: Stainless Steel
  • Clamp Style: Regular
  • Couplers Included: 1
  • System Type: Cold-Air Intake System
  • Mass Air Flow Sensor Adapter Included: Mass Air Flow Sensor Adapter Included When Required
  • Intake Pipe Color / Finish: Silver
  • Intake Pipe Ports: All intake tube ports needed for the specified applications are included
  • Vacuum Tubing Included: Yes
  • Air Filter Large End Diameter: 6 in (152 mm)
  • Weight: 7.8 lb (3.5 kg)
  • Product Box Length: 24.13 in (613 mm)
  • Product Box Width: 12.38 in (314 mm)
  • Product Box Height: 11.5 in (292 mm)

What's Included

  • (1) Hose Clamp #36 - 08530
  • (1) Hose; 2-1/2" to 2-3/4" Tprd.; Black - 084016
  • (1) Hose Clamp #40 - 08554
  • (1) Intake Tube - 27385
  • (1) Hose; 5/8"ID x 14"L, Black - 084083
  • (1) Stud; 6MM-1.00 X 35MM L, SS - 08220
  • (1) Spacer: .625"OD X .250"ID X .250"L - 06555
  • (1) Bracket; "L", Stl. FB/PC - 07804
  • (6) Washer; 6MM Flat, SS - 08269
  • (2) Washer; 1/4" Lock, ZN - 08198
  • (1) Bracket; Long - 07945
  • (2) Nut; 6MM Nylock, Hexhead, SS - 07512
  • (1) Nut; M6 X 1.00, Hexhead, SS - 07506
  • (2) Bolt; M4-0.07 8MM, A/H Cap, SS - 07733
  • (1) Washer; 1/4"ID X 1/2"OD X 1/8"Thk., ZN - 08271
  • (1) Heat Shield - 07625
  • (1) Edge Trim 14" - 102475
  • (1) Edge Trim 23" - 102495
  • (1) Bolt; M6 X 1.00 X 16MM, Buttonhead - 07730
  • (2) Bolt; 6MM-1.00 X 16MM, SS - 07812
  • (1) Hose Clamp #44 - 08577
  • (1) Air Filter - RU-4960

Compatibility

  • 2006-2008 Mazda 3 MPS
