Description

The 8 Bar MAP Sensor EU (MAP8EU) is a high-boost manifold absolute pressure sensor based on the Variohm Eurosensor platform, capable of measuring up to 800 kPa (approximately 7 Bar absolute / 101 psi of boost). This new-enclosure variant is purpose-built for extreme turbocharged and supercharged applications where standard MAP sensors would be out of range.

  • Pressure range: 0–800 kPa absolute
  • Voltage output: 0.5V at 0 kPa, 4.5V at 800 kPa (linear ratiometric)
  • Three-pin connector: Pin A = Ground (0V), Pin B = Power (5V), Pin C = Signal
  • Connector plug and pins included for straightforward installation
  • Compatible with Link G4, G4+, G4X, and G5 ECUs — select Variohm 8 Bar as the MAP sensor type in PC Link

This sensor is ideal for high-output drag, circuit, and time-attack builds running extreme boost levels, providing a reliable and accurate pressure signal well beyond the limits of standard 3 or 4 bar sensors.

Specifications

Compatibility

  • Universal Part

The 8 Bar MAP Sensor EU (MAP8EU) is a high-boost manifold absolute pressure sensor based on the Variohm Eurosensor platform, capable of measuring up to 800 kPa (approximately 7 Bar absolute / 101 psi of boost). This new-enclosure variant is purpose-built for extreme turbocharged and supercharged applications where standard MAP sensors would be out of range.

  • Pressure range: 0–800 kPa absolute
  • Voltage output: 0.5V at 0 kPa, 4.5V at 800 kPa (linear ratiometric)
  • Three-pin connector: Pin A = Ground (0V), Pin B = Power (5V), Pin C = Signal
  • Connector plug and pins included for straightforward installation
  • Compatible with Link G4, G4+, G4X, and G5 ECUs — select Variohm 8 Bar as the MAP sensor type in PC Link

This sensor is ideal for high-output drag, circuit, and time-attack builds running extreme boost levels, providing a reliable and accurate pressure signal well beyond the limits of standard 3 or 4 bar sensors.

  • Universal Part
