Description

Holley marine mechanical fuel pumps range from 110 GPH to 200 GPH for small and big block Chevy applications to meet the fuel demands of most engines.

Holley Marine mechanical pumps are designed with a fuel/fume tube to provide a safe fuel exit in the unlikely event of a diaphragm rupture.

Features

  • High output fuel flow
  • Flows 130+ GPH free flow
  • Shutoff pressure pre-set from 7.5 to 9 psi
  • Fuel pressure regulator is required (recommend Holley P/N 12-704)
  • Heavy duty construction for continuous high rpm operation
  • Redesigned high flow valves always ensure adequate fuel delivery
  • Fuel body casting can be rotated to accommodate various plumbing situations
  • Inlet & outlet tapped for 3/8" NPT
  • Includes Fuel/vapor tube

Specifications

ApplicationMarine BBC
Average Flow Rating130
BrandHolley
ColourSilver
Emission Code5
Free Flow GPH130
Free Flow LPH416
Fuel Pump TypeMechanical
Fuel TypeGasoline
Gasket Or Seal IncludedYes
Grade TypePerformance
Housing MaterialAluminum
Inlet Fitting Thread Size3/8
Inlet Quantity1
Inlet Size3/8 inch NPT
Inlet TypeNPT
MaterialAluminum
Mounting Hardware IncludedNo
Mounting Hole Quantity2
Outlet Fitting Thread Size3/8
Outlet Quantity1
Outlet Size3/8 inch NPT
Outlet TypeNPT
Product TypeFuel Pump
Sale CategoryAir and Fuel Delivery
WarrantyLimited 90 Day

Compatibility

  • Universal Part

Holley marine mechanical fuel pumps range from 110 GPH to 200 GPH for small and big block Chevy applications to meet the fuel demands of most engines.

Holley Marine mechanical pumps are designed with a fuel/fume tube to provide a safe fuel exit in the unlikely event of a diaphragm rupture.

Features

  • High output fuel flow
  • Flows 130+ GPH free flow
  • Shutoff pressure pre-set from 7.5 to 9 psi
  • Fuel pressure regulator is required (recommend Holley P/N 12-704)
  • Heavy duty construction for continuous high rpm operation
  • Redesigned high flow valves always ensure adequate fuel delivery
  • Fuel body casting can be rotated to accommodate various plumbing situations
  • Inlet & outlet tapped for 3/8" NPT
  • Includes Fuel/vapor tube
ApplicationMarine BBC
Average Flow Rating130
BrandHolley
ColourSilver
Emission Code5
Free Flow GPH130
Free Flow LPH416
Fuel Pump TypeMechanical
Fuel TypeGasoline
Gasket Or Seal IncludedYes
Grade TypePerformance
Housing MaterialAluminum
Inlet Fitting Thread Size3/8
Inlet Quantity1
Inlet Size3/8 inch NPT
Inlet TypeNPT
MaterialAluminum
Mounting Hardware IncludedNo
Mounting Hole Quantity2
Outlet Fitting Thread Size3/8
Outlet Quantity1
Outlet Size3/8 inch NPT
Outlet TypeNPT
Product TypeFuel Pump
Sale CategoryAir and Fuel Delivery
WarrantyLimited 90 Day
  • Universal Part
