Description

Pumps are designed for use on all low and high pressure carburetor equipped automobiles, trucks, vans, generators, agriculture, gasoline and diesel engines, marine, construction and agriculture utility equipment. The 12 volt pumps perform in a 12-15 psi range at 50 GPH. Can be used as a lift / priming pump for most diesel engines. Compatible with all fuels and additives. These pumps can be a perfect OE replacement for any of your equipment. Rugged solid state design pumps are a simple two wire hook-up and made in the USA. A regulator may be needed for carbureted applications requiring less fuel pressure. We recommend the Holley 12-803 or 12-804 fuel pressure regulator. Overall dimensions- 4"x 3"x 3"

Features

  • 60” Dry lift/ 12-15 PSI / 50 GPH
  • Self-Priming and Self-Regulating
  • Compatible with gasoline, diesel, bio diesel, E85, blended alcohol and fuel additives
  • Operating temperature range of -40F to + 180F
  • UL Certified
  • Meets Coast Guard Ignition Protection Test Requirements 33CFR183.410 and Fire and Thermo Shock Test Requirements 33CFF183.590
  • Corrosion resistant over 100 hours of salt spray

Specifications

ApplicationUniversal
BrandMighty Mite
ColourSilver
Emission Code5
Free Flow GPH50
Fuel Delivery TypeCarburetor
Fuel Sending Unit IncludedNo
Fuel SystemCarbureted
Fuel TypeGasoline
Fuel TypeE85
Fuel TypeDiesel
Gasket Or Seal IncludedNo
Grade TypePerformance
Inlet Fitting Thread Size1/8
Inlet Thread1/8" NPT
Inlet TypeNPT
Internal Or ExternalExternal
MaterialSteel
Maximum Flow Rating50
Maximum Pressure15
Negative GroundYes
Outlet Fitting Thread Size1/8
Outlet Quantity1
Outlet Thread1/8" NPT
Outlet TypeNPT
Product TypeFuel Pump
Regulator IncludedNo
Sale CategoryAir and Fuel Delivery
Universal Or Specific FitUniversal
Voltage12
WarrantyLimited 90 Day
Wire Quantity2

Compatibility

  • Universal Part

Pumps are designed for use on all low and high pressure carburetor equipped automobiles, trucks, vans, generators, agriculture, gasoline and diesel engines, marine, construction and agriculture utility equipment. The 12 volt pumps perform in a 12-15 psi range at 50 GPH. Can be used as a lift / priming pump for most diesel engines. Compatible with all fuels and additives. These pumps can be a perfect OE replacement for any of your equipment. Rugged solid state design pumps are a simple two wire hook-up and made in the USA. A regulator may be needed for carbureted applications requiring less fuel pressure. We recommend the Holley 12-803 or 12-804 fuel pressure regulator. Overall dimensions- 4"x 3"x 3"

Features

  • 60” Dry lift/ 12-15 PSI / 50 GPH
  • Self-Priming and Self-Regulating
  • Compatible with gasoline, diesel, bio diesel, E85, blended alcohol and fuel additives
  • Operating temperature range of -40F to + 180F
  • UL Certified
  • Meets Coast Guard Ignition Protection Test Requirements 33CFR183.410 and Fire and Thermo Shock Test Requirements 33CFF183.590
  • Corrosion resistant over 100 hours of salt spray
ApplicationUniversal
BrandMighty Mite
ColourSilver
Emission Code5
Free Flow GPH50
Fuel Delivery TypeCarburetor
Fuel Sending Unit IncludedNo
Fuel SystemCarbureted
Fuel TypeGasoline
Fuel TypeE85
Fuel TypeDiesel
Gasket Or Seal IncludedNo
Grade TypePerformance
Inlet Fitting Thread Size1/8
Inlet Thread1/8" NPT
Inlet TypeNPT
Internal Or ExternalExternal
MaterialSteel
Maximum Flow Rating50
Maximum Pressure15
Negative GroundYes
Outlet Fitting Thread Size1/8
Outlet Quantity1
Outlet Thread1/8" NPT
Outlet TypeNPT
Product TypeFuel Pump
Regulator IncludedNo
Sale CategoryAir and Fuel Delivery
Universal Or Specific FitUniversal
Voltage12
WarrantyLimited 90 Day
Wire Quantity2
  • Universal Part
