Description

STREET SERIES - Direct OE Replacement

DBA's Standard Rotor series are direct fitment replacement rotors for all types of vehicles.





Direct OE Replacement - Stage 1 Street Series Specs

  • Patented 'Kangaroo Paw' ventilation design* (not available on all part numbers)
  • CBN (Cubic Boron Nitride) machine turned
  • Moisture proof corrosion protection packaging
  • En-Shield anti-rust coating available on selected part numbers



*Due to some vehicles being fitted with different discs from factory, please confirm your current standard disc specs with the specifications provided below.



Disc Brakes Australia - 100% confidence in fitment every time, not the cheap inferior alternative!  Australian engineered and quality assured to the highest possible standards for the safety of drivers the world over!  Manufacturing to OEM standards are our minimum requiremennts.  With more than three decades of manufacturing expertise, DBA continues to supply premium performance disc brake rotors from its manufacturing plant in Sydney.  As Australia's most highly awarded manufacturer of automotive aftermarket parts, DBA's performance rotors are distributed in over twenty-four countries.  DBA's OEM replacement rotor series includes Standard, Slotted and Cross-Drilled models with added extras like protective paint coatings, T2 wiper slots extending pad life, En-Shield rust free protection, X Gold catering for the big brake look and Clubspec T3 4000 & 5000 series performance and motorsport rotors!

Specifications

Diameter [mm] 287
Height [mm] 65
Thickness [mm] 28
Minimum Thickness [mm] 25.6
Inner Diameter [mm] 71.8
Pitch Circle Ø [mm] 114.3
Weight [kg] 7.6
Number of Holes 5
Class standard
Disc Vent standard

Compatibility

  • 1999 - 2002 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.0 MPFI AU Sedan 157KW
  • 1999 - 2002 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.0 MPFI VCT AU Sedan 168KW
  • 1999 - 2002 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 5.0 MPFI V8 AU Sedan 175KW
  • 1998 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI (AU, AUII, AUIII) AU Sedan 157KW
  • 2000 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AUII, AUIII) AU Sedan 172KW
  • 1998 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 5.0 MPFI V8 (AU, AUII, AUIII) AU Sedan 175KW
  • 2000 - 2001 > FORD AUSTRALIA > FALCON > Petrol Engine 5.0 MPFI V8 XR8 (AUII) AU Sedan 200KW
  • 2001 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 5.0 MPFI V8 XR8 (AU, AUII) AU Sedan 220KW
  • 2002 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 5.6 MPFI V8 XR8 Pursuit (AU, AUII) AU Sedan 250KW
  • 1999 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI (AU, AUII, AUIII) AU Ute 157KW
  • 2002 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 5.6 MPFI V8 XR8 Pursuit (AUIII) AU Ute 250KW
  • 1999 - 2001 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AU, AUII, AUIII) AU Ute 164KW
  • 2001 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AUII, AUIII) AU Ute 172KW
  • 1999 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI (AU, AUII, AUIII) AU Platform/Chassis 157KW
  • 1999 - 2001 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AU, AUII, AUIII) AU Platform/Chassis 164KW
  • 2001 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AUII, AUIII) AU Platform/Chassis 172KW
  • 1998 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI (AU, AUII, AUIII) AU Wagon 157KW
  • 1998 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 LPGFI (AU, AUII, AUIII) AU Wagon 143KW
  • 1999 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 LPGFI (AU, AUII, AUIII) AU Platform/Chassis 143KW
  • 2000 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 LPGFI (AUII, AUIII) AU Sedan 143KW
  • 1999 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 LPGFI (AU, AUII, AUIII) AU Ute 143KW
  • 1998 - 2000 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.0 MPFI (AU) AU Wagon 164KW
  • 2000 - 2002 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.0 MPFI VCT (AUII, AUIII) AU Wagon 172KW
  • 1998 - 2002 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 5.0 MPFI V8 (AU, AUII, AUIII) AU Wagon 175KW
  • 1998 - 2000 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.0 MPFI (AU) AU Sedan 164KW
  • 2000 - 2002 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.0 MPFI VCT (AUII, AUIII) AU Sedan 172KW
  • 2001 - 2002 > FORD AUSTRALIA > TICKFORD TE 50 > Petrol Engine 5.6 i V8 AU Sedan 250KW
  • 2000 - 2001 > FORD AUSTRALIA > TICKFORD TE 50 > Petrol Engine 5.0 i V8 AU Sedan 220KW
  • 1999 - 2002 > FORD AUSTRALIA > LTD > Petrol Engine 5.0 MPFI V8 AU Sedan 185KW

STREET SERIES - Direct OE Replacement

DBA's Standard Rotor series are direct fitment replacement rotors for all types of vehicles.





Direct OE Replacement - Stage 1 Street Series Specs

  • Patented 'Kangaroo Paw' ventilation design* (not available on all part numbers)
  • CBN (Cubic Boron Nitride) machine turned
  • Moisture proof corrosion protection packaging
  • En-Shield anti-rust coating available on selected part numbers



*Due to some vehicles being fitted with different discs from factory, please confirm your current standard disc specs with the specifications provided below.



Disc Brakes Australia - 100% confidence in fitment every time, not the cheap inferior alternative!  Australian engineered and quality assured to the highest possible standards for the safety of drivers the world over!  Manufacturing to OEM standards are our minimum requiremennts.  With more than three decades of manufacturing expertise, DBA continues to supply premium performance disc brake rotors from its manufacturing plant in Sydney.  As Australia's most highly awarded manufacturer of automotive aftermarket parts, DBA's performance rotors are distributed in over twenty-four countries.  DBA's OEM replacement rotor series includes Standard, Slotted and Cross-Drilled models with added extras like protective paint coatings, T2 wiper slots extending pad life, En-Shield rust free protection, X Gold catering for the big brake look and Clubspec T3 4000 & 5000 series performance and motorsport rotors!

Diameter [mm] 287
Height [mm] 65
Thickness [mm] 28
Minimum Thickness [mm] 25.6
Inner Diameter [mm] 71.8
Pitch Circle Ø [mm] 114.3
Weight [kg] 7.6
Number of Holes 5
Class standard
Disc Vent standard
  • 1999 - 2002 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.0 MPFI AU Sedan 157KW
  • 1999 - 2002 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.0 MPFI VCT AU Sedan 168KW
  • 1999 - 2002 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 5.0 MPFI V8 AU Sedan 175KW
  • 1998 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI (AU, AUII, AUIII) AU Sedan 157KW
  • 2000 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AUII, AUIII) AU Sedan 172KW
  • 1998 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 5.0 MPFI V8 (AU, AUII, AUIII) AU Sedan 175KW
  • 2000 - 2001 > FORD AUSTRALIA > FALCON > Petrol Engine 5.0 MPFI V8 XR8 (AUII) AU Sedan 200KW
  • 2001 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 5.0 MPFI V8 XR8 (AU, AUII) AU Sedan 220KW
  • 2002 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 5.6 MPFI V8 XR8 Pursuit (AU, AUII) AU Sedan 250KW
  • 1999 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI (AU, AUII, AUIII) AU Ute 157KW
  • 2002 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 5.6 MPFI V8 XR8 Pursuit (AUIII) AU Ute 250KW
  • 1999 - 2001 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AU, AUII, AUIII) AU Ute 164KW
  • 2001 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AUII, AUIII) AU Ute 172KW
  • 1999 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI (AU, AUII, AUIII) AU Platform/Chassis 157KW
  • 1999 - 2001 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AU, AUII, AUIII) AU Platform/Chassis 164KW
  • 2001 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI XR6 (AUII, AUIII) AU Platform/Chassis 172KW
  • 1998 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 MPFI (AU, AUII, AUIII) AU Wagon 157KW
  • 1998 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 LPGFI (AU, AUII, AUIII) AU Wagon 143KW
  • 1999 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 LPGFI (AU, AUII, AUIII) AU Platform/Chassis 143KW
  • 2000 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 LPGFI (AUII, AUIII) AU Sedan 143KW
  • 1999 - 2002 > FORD AUSTRALIA > FALCON > Petrol Engine 4.0 LPGFI (AU, AUII, AUIII) AU Ute 143KW
  • 1998 - 2000 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.0 MPFI (AU) AU Wagon 164KW
  • 2000 - 2002 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.0 MPFI VCT (AUII, AUIII) AU Wagon 172KW
  • 1998 - 2002 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 5.0 MPFI V8 (AU, AUII, AUIII) AU Wagon 175KW
  • 1998 - 2000 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.0 MPFI (AU) AU Sedan 164KW
  • 2000 - 2002 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.0 MPFI VCT (AUII, AUIII) AU Sedan 172KW
  • 2001 - 2002 > FORD AUSTRALIA > TICKFORD TE 50 > Petrol Engine 5.6 i V8 AU Sedan 250KW
  • 2000 - 2001 > FORD AUSTRALIA > TICKFORD TE 50 > Petrol Engine 5.0 i V8 AU Sedan 220KW
  • 1999 - 2002 > FORD AUSTRALIA > LTD > Petrol Engine 5.0 MPFI V8 AU Sedan 185KW
