Description

4000 SERIES disc brake rotors are a direct replacement single piece brake rotor, designed for drivers seeking upgraded performance braking above and beyond standard OE levels.

Cast from high carbon alloyed iron and undergoing Thermal Stability Profiling, DBA's metallurgy can handle the increased stress and heat generated under intense braking applications, time and time again.

Featuring DBA's Kangaroo Paw ventilation that implements a series of 144 diamond and teardrop patterned pillars, DBA achieves up to a 30% increase in surface area and 20% improvement in cooling efficiency (as compared to a traditional straight vane design).

4000 SERIES T3 is the ultimate in direct replacement single piece performance brake rotors. Featuring all the benefits of the 4000 Series plus DBA's patented world renowned T3 bi directional slot design.

Built on the foundations of DBA's T2 slot, the T3 slot design features additional, precise, CNC machined tri symmetrical slots, resulting in an even quieter, more responsive and smoother brake pedal feel. The T3 slot increases the number of exit points for brake pad friction dust and gases to escape through, further increasing the consistency and effectiveness of every brake stop.

We recommend a T3 slot for high performance and heavy off-roading applications.

Features

  • Surface Design: Slots and/or chamfered drill holes facilitate the exit of friction dust and gasses, for a quieter and more responsive pedal feel.
  • Anti Rust: Painted non-friction areas to prevent rust and enhance appearance.
  • BI-Directional Use: Symmetrical slotting and/or drilling for universal left/right use.
  • Thermal Stability Profiling: Heat treatment cycles realign the microstructure of the iron, resulting in increased rotor stability and durability.
  • Thermal Efficiency: Centre-split core castings for increased heat transfer and thermal efficiency.
  • CBN: Cubic Boron Nitride (CBN) machine turned finish, minimising disc thickness variation and the potential for pad "knock" and resulting premature wear.
  • Thermographic Heat Paint: Paint markings change colour at specific temperature thresholds to assist with the monitoring of braking temperatures and rotor fatigue.
  • High Carbon Alloyed Iron: Formulation allows for optimal interaction with DBA's thermal stability profiling (TSP). Increases the capacity of the rotor to handle constant and extreme heat over prolonged periods.
  • Kangaroo Paw: Unique Kangaroo Paw vane design for up to 20% better heat dissipation, increasing braking effectiveness and prolonging brake life.

Specifications

  • Quantity: 2 (pair)
  • Product Variant: 4000 Series
  • Product SubVariant: T3
  • Warranty: 12 months/ 20,000km/ 12,000 miles
  • Axle: Front
  • Vane Design: KP Vents
  • Outer diameter [mm]: 280
  • Height [mm]: 54
  • Brake Disc Thickness [mm]: 30
  • Minimum Thickness [mm]: 28
  • Centering Diameter [mm]: 68
  • Number of Holes: 5
  • Pitch Circle Diameter: 114.30
  • Surface Design: Slotted
  • Driving Style: 4WD GVM, 4WD Offroad, Performance, Towing < 750kg

What's Included

  • 2x Front 4000 Series T3 Brake Rotors

Compatibility

  • 1989-1997 Nissan 300ZX Petrol Engine 3.0 Twin Turbo Z32 Coupe 208KW
  • 1990-1997 Nissan 300ZX Petrol Engine 3.0 Twin Turbo Z32 Coupe 197KW
  • 1994-1999 Nissan Silvia Petrol Engine 2.0 Turbo S14 Coupe 162KW - Suits From 10/94
  • 1994-1996 Nissan Silvia Petrol Engine 2.0 i 16V Turbo S14 Coupe 147KW - Suits From 10/94
  • 1999-2003 Nissan Silvia Petrol Engine 2000 Turbo S15 Coupe 184KW - Suits From 11/00
  • 1999-2003 Nissan Silvia Petrol Engine Turbo 16V S15 Coupe 147KW - Suits From 11/00
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 (HCR32) R32 Coupe 114KW
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 (HR32) R32 Sedan 114KW
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 4x4 R32 Sedan 114KW
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 Turbo (HCR32) R32 Coupe 158KW - Suits From 5/89 To 7/93
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 Turbo (HCR32) R32 Sedan 158KW - Suits From 5/89 To 7/93
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 Turbo 4x4 (HNR32) R32 Coupe 158KW - Suits From 5/89 To 7/93
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 Turbo 4x4 (HNR32) R32 Sedan 158KW - Suits From 5/89 To 7/93

4000 SERIES disc brake rotors are a direct replacement single piece brake rotor, designed for drivers seeking upgraded performance braking above and beyond standard OE levels.

Cast from high carbon alloyed iron and undergoing Thermal Stability Profiling, DBA's metallurgy can handle the increased stress and heat generated under intense braking applications, time and time again.

Featuring DBA's Kangaroo Paw ventilation that implements a series of 144 diamond and teardrop patterned pillars, DBA achieves up to a 30% increase in surface area and 20% improvement in cooling efficiency (as compared to a traditional straight vane design).

4000 SERIES T3 is the ultimate in direct replacement single piece performance brake rotors. Featuring all the benefits of the 4000 Series plus DBA's patented world renowned T3 bi directional slot design.

Built on the foundations of DBA's T2 slot, the T3 slot design features additional, precise, CNC machined tri symmetrical slots, resulting in an even quieter, more responsive and smoother brake pedal feel. The T3 slot increases the number of exit points for brake pad friction dust and gases to escape through, further increasing the consistency and effectiveness of every brake stop.

We recommend a T3 slot for high performance and heavy off-roading applications.

Features

  • Surface Design: Slots and/or chamfered drill holes facilitate the exit of friction dust and gasses, for a quieter and more responsive pedal feel.
  • Anti Rust: Painted non-friction areas to prevent rust and enhance appearance.
  • BI-Directional Use: Symmetrical slotting and/or drilling for universal left/right use.
  • Thermal Stability Profiling: Heat treatment cycles realign the microstructure of the iron, resulting in increased rotor stability and durability.
  • Thermal Efficiency: Centre-split core castings for increased heat transfer and thermal efficiency.
  • CBN: Cubic Boron Nitride (CBN) machine turned finish, minimising disc thickness variation and the potential for pad "knock" and resulting premature wear.
  • Thermographic Heat Paint: Paint markings change colour at specific temperature thresholds to assist with the monitoring of braking temperatures and rotor fatigue.
  • High Carbon Alloyed Iron: Formulation allows for optimal interaction with DBA's thermal stability profiling (TSP). Increases the capacity of the rotor to handle constant and extreme heat over prolonged periods.
  • Kangaroo Paw: Unique Kangaroo Paw vane design for up to 20% better heat dissipation, increasing braking effectiveness and prolonging brake life.
  • Quantity: 2 (pair)
  • Product Variant: 4000 Series
  • Product SubVariant: T3
  • Warranty: 12 months/ 20,000km/ 12,000 miles
  • Axle: Front
  • Vane Design: KP Vents
  • Outer diameter [mm]: 280
  • Height [mm]: 54
  • Brake Disc Thickness [mm]: 30
  • Minimum Thickness [mm]: 28
  • Centering Diameter [mm]: 68
  • Number of Holes: 5
  • Pitch Circle Diameter: 114.30
  • Surface Design: Slotted
  • Driving Style: 4WD GVM, 4WD Offroad, Performance, Towing < 750kg
  • 2x Front 4000 Series T3 Brake Rotors
  • 1989-1997 Nissan 300ZX Petrol Engine 3.0 Twin Turbo Z32 Coupe 208KW
  • 1990-1997 Nissan 300ZX Petrol Engine 3.0 Twin Turbo Z32 Coupe 197KW
  • 1994-1999 Nissan Silvia Petrol Engine 2.0 Turbo S14 Coupe 162KW - Suits From 10/94
  • 1994-1996 Nissan Silvia Petrol Engine 2.0 i 16V Turbo S14 Coupe 147KW - Suits From 10/94
  • 1999-2003 Nissan Silvia Petrol Engine 2000 Turbo S15 Coupe 184KW - Suits From 11/00
  • 1999-2003 Nissan Silvia Petrol Engine Turbo 16V S15 Coupe 147KW - Suits From 11/00
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 (HCR32) R32 Coupe 114KW
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 (HR32) R32 Sedan 114KW
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 4x4 R32 Sedan 114KW
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 Turbo (HCR32) R32 Coupe 158KW - Suits From 5/89 To 7/93
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 Turbo (HCR32) R32 Sedan 158KW - Suits From 5/89 To 7/93
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 Turbo 4x4 (HNR32) R32 Coupe 158KW - Suits From 5/89 To 7/93
  • 1989-1993 Nissan Skyline Petrol Engine 2.0 Turbo 4x4 (HNR32) R32 Sedan 158KW - Suits From 5/89 To 7/93
