Description

STREET SERIES direct replacement rotors are ideal for drivers seeking an OE level performance upgrade.

STREET SERIES rotors are the perfect option for drivers looking for a direct OE replacement disc rotor that is built using the highest quality manufacturing processes, materials and proven safety, thanks to DBA's over 40 years experience in braking.

We recommend STREET SERIES for daily drivers, light commercial and SUV applications.

EnShield technology has been introduced to the Street Series range to provide corrosion resistant rotors, keeping the rotors looking good throughout service life.

The EnShield process begins with a zinc/aluminium water based coating being applied to the entire rotor surface and is then baked on.

EnShield rotors are denoted by the suffix (E) in Street Series part numbers.

Features

  • Surface Design: Slots and/or chamfered drill holes facilitate the exit of friction dust and gasses, for a quieter and more responsive pedal feel.
  • Anti Rust: Painted non-friction areas to prevent rust and enhance appearance, or full En-shield coating to protect the rotor and alleviate the need for pre-installation cleaning.
  • BI-Directional Use: Symmetrical slotting and/or drilling for universal left/right use.
  • Thermal Efficiency: Centre-split core castings for increased heat transfer and thermal efficiency.
  • CBN: CBN (Cubic Boron Nitride) machine turned finish, minimising disc thickness variation and the potential for pad "knock" and resulting premature wear.
  • Kangaroo Paw: Unique Kangaroo Paw vane design for up to 20% better heat dissipation, increasing braking effectiveness and prolonging brake life.

Specifications

  • Quantity: 2 (pair)
  • Product Variant: Street Series
  • Product SubVariant: En-Shield
  • Warranty: 12 months/ 20,000km/ 12,000 miles
  • Axle: Front
  • Outer diameter [mm]: 280
  • Height [mm]: 44.4
  • Brake Disc Thickness [mm]: 23
  • Minimum Thickness [mm]: 21.5
  • Centering Diameter [mm]: 69
  • Number of Holes: 5
  • Pitch Circle Diameter: 114.30
  • Surface Design: Plain
  • Driving Style: 4WD, 4WD Offroad, Family SUV, Passenger car, Towing < 750kg, Utility or Van

What's Included

  • 2x Front Street Series En-Shield Brake Rotors

Compatibility

  • 2010-2015 Hyundai Elantra Petrol Engine 1.8 MD,UD Sedan 110KW - Suits From 6/11
  • 2015-2020 Hyundai Elantra Petrol Engine 2.0 AD,ADA Sedan 112KW
  • 2017-2023 Hyundai Kona Petrol Engine 2.0 OS,OSE,OSI SUV 110KW
  • 2021-2023 Hyundai Kona Petrol Engine 2.0 OS,OSE,OSI SUV 110KW
  • 2011-2017 Hyundai Veloster Petrol Engine 1.6 GDI FS Coupe 103KW - Suits From 2012
  • 2018-2026 Hyundai Veloster Petrol Engine 2.0 MPI JS,JSN Coupe 110KW
  • 2011-2015 Hyundai i30 Diesel 1.6 CRDi GD Hatchback 94KW
  • 2011-2016 Hyundai i30 Petrol Engine 1.6 GDI GD Hatchback 99KW
  • 2012-2015 Hyundai i30 Diesel 1.6 CRDi GD Wagon 94KW
  • 2012-2016 Hyundai i30 Petrol Engine 1.6 GDI GD Wagon 99KW
  • 2012-2017 Hyundai i30 Petrol Engine 1.8 GD Hatchback 110KW
  • 2013-2015 Hyundai i30 Petrol Engine 1.6 GDI Coupe 99KW
  • 2013-2017 Hyundai i30 Petrol Engine 1.8 GD Hatchback 107KW
  • 2014-2016 Hyundai i30 Diesel 1.6 CRDi GD Hatchback 100KW
  • 2014-2017 Hyundai i30 Petrol Engine 2.0 GD Hatchback 124KW
  • 2016-2020 Hyundai i30 Diesel 1.6 CRDi PDE,PD,PDEN Hatchback 100KW
  • 2016-2026 Hyundai i30 Petrol Engine 2.0 PDE,PD,PDEN Hatchback 120KW
  • 2013-2016 Kia Cerato Petrol Engine 1.8 YD Hatchback 110KW - 280mm Dia X 23mm Thk X 44.4mm Hgt
  • 2013-2016 Kia Cerato Petrol Engine 1.8 YD,YDM Sedan 110KW - Dia 280mm [ 15 Inch wheel ]
  • 2013-2016 Kia Cerato Petrol Engine 2.0 GDI YD Hatchback 129KW
  • 2013-2016 Kia Cerato Petrol Engine 2.0 GDI YD,YDM Sedan 129KW
  • 2016-2018 Kia Cerato Petrol Engine 2.0 CVVT YD Hatchback 112KW - Solid Rotor, 262mm Dia X 10mm Thk X 45mm Hgt
  • 2016-2018 Kia Cerato Petrol Engine 2.0 MPi YD,YDM Sedan 112KW
  • 2018-2026 Kia Cerato Petrol Engine 2.0 MPi BD,BDM Hatchback 112KW
  • 2018-2026 Kia Cerato Petrol Engine 2.0 MPi BD,BDM Sedan 112KW
  • 2019-2026 Kia Seltos Petrol Engine 2.0 MPi (SP2) SP2,SP2I SUV 110KW
  • 2014-2018 Kia Soul Petrol Engine 2.0 CVVT PS Hatchback 112KW
  • 2014-2018 Kia Soul Petrol Engine 2.0 CVVT PS Hatchback 113KW

STREET SERIES direct replacement rotors are ideal for drivers seeking an OE level performance upgrade.

STREET SERIES rotors are the perfect option for drivers looking for a direct OE replacement disc rotor that is built using the highest quality manufacturing processes, materials and proven safety, thanks to DBA's over 40 years experience in braking.

We recommend STREET SERIES for daily drivers, light commercial and SUV applications.

EnShield technology has been introduced to the Street Series range to provide corrosion resistant rotors, keeping the rotors looking good throughout service life.

The EnShield process begins with a zinc/aluminium water based coating being applied to the entire rotor surface and is then baked on.

EnShield rotors are denoted by the suffix (E) in Street Series part numbers.

Features

  • Surface Design: Slots and/or chamfered drill holes facilitate the exit of friction dust and gasses, for a quieter and more responsive pedal feel.
  • Anti Rust: Painted non-friction areas to prevent rust and enhance appearance, or full En-shield coating to protect the rotor and alleviate the need for pre-installation cleaning.
  • BI-Directional Use: Symmetrical slotting and/or drilling for universal left/right use.
  • Thermal Efficiency: Centre-split core castings for increased heat transfer and thermal efficiency.
  • CBN: CBN (Cubic Boron Nitride) machine turned finish, minimising disc thickness variation and the potential for pad "knock" and resulting premature wear.
  • Kangaroo Paw: Unique Kangaroo Paw vane design for up to 20% better heat dissipation, increasing braking effectiveness and prolonging brake life.
  • Quantity: 2 (pair)
  • Product Variant: Street Series
  • Product SubVariant: En-Shield
  • Warranty: 12 months/ 20,000km/ 12,000 miles
  • Axle: Front
  • Outer diameter [mm]: 280
  • Height [mm]: 44.4
  • Brake Disc Thickness [mm]: 23
  • Minimum Thickness [mm]: 21.5
  • Centering Diameter [mm]: 69
  • Number of Holes: 5
  • Pitch Circle Diameter: 114.30
  • Surface Design: Plain
  • Driving Style: 4WD, 4WD Offroad, Family SUV, Passenger car, Towing < 750kg, Utility or Van
  • 2x Front Street Series En-Shield Brake Rotors
  • 2010-2015 Hyundai Elantra Petrol Engine 1.8 MD,UD Sedan 110KW - Suits From 6/11
  • 2015-2020 Hyundai Elantra Petrol Engine 2.0 AD,ADA Sedan 112KW
  • 2017-2023 Hyundai Kona Petrol Engine 2.0 OS,OSE,OSI SUV 110KW
  • 2021-2023 Hyundai Kona Petrol Engine 2.0 OS,OSE,OSI SUV 110KW
  • 2011-2017 Hyundai Veloster Petrol Engine 1.6 GDI FS Coupe 103KW - Suits From 2012
  • 2018-2026 Hyundai Veloster Petrol Engine 2.0 MPI JS,JSN Coupe 110KW
  • 2011-2015 Hyundai i30 Diesel 1.6 CRDi GD Hatchback 94KW
  • 2011-2016 Hyundai i30 Petrol Engine 1.6 GDI GD Hatchback 99KW
  • 2012-2015 Hyundai i30 Diesel 1.6 CRDi GD Wagon 94KW
  • 2012-2016 Hyundai i30 Petrol Engine 1.6 GDI GD Wagon 99KW
  • 2012-2017 Hyundai i30 Petrol Engine 1.8 GD Hatchback 110KW
  • 2013-2015 Hyundai i30 Petrol Engine 1.6 GDI Coupe 99KW
  • 2013-2017 Hyundai i30 Petrol Engine 1.8 GD Hatchback 107KW
  • 2014-2016 Hyundai i30 Diesel 1.6 CRDi GD Hatchback 100KW
  • 2014-2017 Hyundai i30 Petrol Engine 2.0 GD Hatchback 124KW
  • 2016-2020 Hyundai i30 Diesel 1.6 CRDi PDE,PD,PDEN Hatchback 100KW
  • 2016-2026 Hyundai i30 Petrol Engine 2.0 PDE,PD,PDEN Hatchback 120KW
  • 2013-2016 Kia Cerato Petrol Engine 1.8 YD Hatchback 110KW - 280mm Dia X 23mm Thk X 44.4mm Hgt
  • 2013-2016 Kia Cerato Petrol Engine 1.8 YD,YDM Sedan 110KW - Dia 280mm [ 15 Inch wheel ]
  • 2013-2016 Kia Cerato Petrol Engine 2.0 GDI YD Hatchback 129KW
  • 2013-2016 Kia Cerato Petrol Engine 2.0 GDI YD,YDM Sedan 129KW
  • 2016-2018 Kia Cerato Petrol Engine 2.0 CVVT YD Hatchback 112KW - Solid Rotor, 262mm Dia X 10mm Thk X 45mm Hgt
  • 2016-2018 Kia Cerato Petrol Engine 2.0 MPi YD,YDM Sedan 112KW
  • 2018-2026 Kia Cerato Petrol Engine 2.0 MPi BD,BDM Hatchback 112KW
  • 2018-2026 Kia Cerato Petrol Engine 2.0 MPi BD,BDM Sedan 112KW
  • 2019-2026 Kia Seltos Petrol Engine 2.0 MPi (SP2) SP2,SP2I SUV 110KW
  • 2014-2018 Kia Soul Petrol Engine 2.0 CVVT PS Hatchback 112KW
  • 2014-2018 Kia Soul Petrol Engine 2.0 CVVT PS Hatchback 113KW
