Description

STREET SERIES direct replacement rotors are ideal for drivers seeking an OE level performance upgrade.

STREET SERIES rotors are the perfect option for drivers looking for a direct OE replacement disc rotor that is built using the highest quality manufacturing processes, materials and proven safety, thanks to DBA's over 40 years experience in braking.

We recommend STREET SERIES for daily drivers, light commercial and SUV applications.

EnShield technology has been introduced to the Street Series range to provide corrosion resistant rotors, keeping the rotors looking good throughout service life.

The EnShield process begins with a zinc/aluminium water based coating being applied to the entire rotor surface and is then baked on.

EnShield rotors are denoted by the suffix (E) in Street Series part numbers.

Features

  • Surface Design: Slots and/or chamfered drill holes facilitate the exit of friction dust and gasses, for a quieter and more responsive pedal feel.
  • Anti Rust: Painted non-friction areas to prevent rust and enhance appearance, or full En-shield coating to protect the rotor and alleviate the need for pre-installation cleaning.
  • BI-Directional Use: Symmetrical slotting and/or drilling for universal left/right use.
  • Thermal Efficiency: Centre-split core castings for increased heat transfer and thermal efficiency.
  • CBN: CBN (Cubic Boron Nitride) machine turned finish, minimising disc thickness variation and the potential for pad "knock" and resulting premature wear.
  • Kangaroo Paw: Unique Kangaroo Paw vane design for up to 20% better heat dissipation, increasing braking effectiveness and prolonging brake life.

Specifications

  • Quantity: 2 (pair)
  • Product Variant: Street Series
  • Product SubVariant: En-Shield
  • Warranty: 12 months/ 20,000km/ 12,000 miles
  • Axle: Front
  • Outer diameter [mm]: 294
  • Height [mm]: 45.5
  • Brake Disc Thickness [mm]: 26
  • Minimum Thickness [mm]: 24.4
  • Centering Diameter [mm]: 69
  • Number of Holes: 5
  • Pitch Circle Diameter: 114.30
  • Surface Design: Plain
  • Driving Style: 4WD, 4WD Offroad, Family SUV, Passenger car, Towing < 750kg, Utility or Van

What's Included

  • 2x Front Street Series En-Shield Brake Rotors

Compatibility

  • 2007-2010 Chrysler Sebring Diesel 2.0 CRD JS Sedan 103KW
  • 2007-2010 Chrysler Sebring Petrol Engine 2.4 VVT JS Sedan 125KW
  • 2007-2010 Chrysler Sebring Petrol Engine 2.7 Flexfuel JS Convertible 137KW
  • 2007-2010 Chrysler Sebring Petrol Engine 2.7 JS Convertible 137KW
  • 2007-2010 Chrysler Sebring Petrol Engine 2.7 VVT JS Sedan 137KW
  • 2012-2013 Citroen C4 Aircross Petrol Engine 2.0 AWC SUV 110KW
  • 2007-2011 Dodge Avenger Petrol Engine 2.0 JS Sedan 115KW - Suits 2007-2010
  • 2007-2014 Dodge Avenger Petrol Engine 2.4 JS Sedan 125KW - Suits 2007-2010
  • 2007-2010 Dodge Avenger Petrol Engine 2.7 JS Sedan 137KW
  • 2006-2010 Dodge Caliber Diesel 2.0 CRD Hatchback 103KW - Suits From 10/06; With Rear Disc
  • 2006-2009 Dodge Caliber Petrol Engine 1.8 Hatchback 110KW - Suits From 10/06; With Rear Disc
  • 2006-2012 Dodge Caliber Petrol Engine 2.0 Hatchback 115KW - Suits From 10/06; With Rear Disc
  • 2006-2007 Dodge Caliber Petrol Engine 2.4 Hatchback 125KW
  • 2006-2010 Jeep Compass Diesel 2.0 CRD 4x4 MK49 SUV 103KW - Suits From 2007
  • 2006-2016 Jeep Compass Petrol Engine 2.4 4x4 MK49 SUV 125KW - Suits From 2007
  • 2011-2017 Jeep Compass Petrol Engine 2.0 MK49 SUV 115KW - Suits 2007-2015
  • 2007-2017 Jeep Patriot Diesel 2.0 CRD 4x4 MK74 Closed Off-Road Vehicle 103KW
  • 2007-2017 Jeep Patriot Petrol Engine 2.4 4x4 MK74 Closed Off-Road Vehicle 125KW
  • 2008-2017 Jeep Patriot Petrol Engine 2.4 Eco + 4x4 MK74 Closed Off-Road Vehicle 125KW
  • 2009-2017 Jeep Patriot Petrol Engine 2.4 MK74 Closed Off-Road Vehicle 125KW
  • 2011-2017 Jeep Patriot Petrol Engine 2.0 MK74 Closed Off-Road Vehicle 115KW
  • 2010-2013 Mitsubishi ASX Diesel 1.8 DI-D 4WD (GA6W) GA_W_,XA,XB,XC,XD SUV 110KW - Suits From 7/10
  • 2010-2026 Mitsubishi ASX Petrol Engine 2.0 MIVEC (GA2W) GA_W_,XA,XB,XC,XD SUV 110KW
  • 2010-2014 Mitsubishi ASX Petrol Engine 2.0 MIVEC 4WD GA_W_,XA,XB,XC,XD SUV 110KW
  • 2013-2018 Mitsubishi ASX Diesel 2.2 DI-D 4WD (GA8W) GA_W_,XA,XB,XC,XD SUV 110KW
  • 2019-2026 Mitsubishi ASX Petrol Engine 2.4 i (GA5W) GA_W_,XA,XB,XC,XD SUV 123KW
  • 2007-2026 Mitsubishi Delica D5 Petrol Engine 2.4 4WD (CV5W) CV_W MPV 125KW
  • 2017-2026 Mitsubishi Eclipse Cross Petrol Engine 1.5 (GK1W) GK_,GL_,YA,YB SUV 110KW
  • 2017-2026 Mitsubishi Eclipse Cross Petrol Engine 1.5 4WD (GK1W) GK_,GL_,YA,YB SUV 110KW
  • 2004-2010 Mitsubishi Grandis Petrol Engine 2.4 MIVEC (NA4W) NA_W,BA MPV 121KW
  • 2008-2016 Mitsubishi Lancer Petrol Engine 2.4 i (CX5A) CX_A,CJ Hatchback 125KW
  • 2008-2016 Mitsubishi Lancer Petrol Engine 2.4 i (CY5A) CY_A,CZ_A,CJ Sedan 125KW - FROM 03/2009 [ 294MM X 26 NEW THICKNESS ]
  • 2006-2012 Mitsubishi Outlander Petrol Engine 2.4 (CW5W) ZG,ZH SUV 125KW
  • 2006-2012 Mitsubishi Outlander Petrol Engine 2.4 4WD (CW5W) ZG,ZH SUV 125KW
  • 2006-2012 Mitsubishi Outlander Petrol Engine 3.0 4WD (CW6W) ZG,ZH SUV 162KW
  • 2011-2012 Mitsubishi Outlander Petrol Engine 3.0 4WD (CW6W) CW_W,ZG,ZH SUV 169KW
  • 2012-2021 Mitsubishi Outlander Diesel 2.2 DI-D 4WD (GF6W) GG_W,GF_W,ZJ,ZL,ZK SUV 110KW
  • 2012-2021 Mitsubishi Outlander Petrol Engine 2.0 (GF7W) GG_W,GF_W,ZJ,ZL,ZK SUV 110KW
  • 2012-2021 Mitsubishi Outlander Petrol Engine 2.4 (GF8W) GG_W,GF_W,ZJ,ZL,ZK SUV 124KW
  • 2012-2021 Mitsubishi Outlander Petrol Engine 2.4 4WD (GF8W) GG_W,GF_W,ZJ,ZL,ZK SUV 124KW
  • 2012-2017 Peugeot 4008 Petrol Engine 2.0 AWC SUV 110KW
  • 2013-2017 Peugeot 4008 Petrol Engine 2.0 SUV 110KW
