Description

Boosted Turbocharger Replacement Core.

As another way of backing up our excellent Boosted Turbocharger range, we stock replacement core's for all popular Boosted Turbo models. This way if you have a mis-hapthat has damaged either of thewheels or even the internals of the turbocharger you can easily purchase the core and swap it out. These cores are designed to suit Boosted Turbochargers specifically however you may find some crossover on other brands thathave a similar core design.

Specifications

BOOSTED 98102 Core Specifications

Recommended horsepower rating:  1000-2500HP
Recommended engine displacement:  3.0L to 7.0L

- 360¬? journal bearing
- 7075 billet 7 + 7 compressor wheel
- This is an oil cooled turbocharger
- Must use a-6AN oil feel line to maintaincore temperature (Warranty VOID if not used)
- 1/4" NPT oilfeed fitting (sold separately)or a 38mm 2-bolt oil feed plate with M8 x 1.25mm thread size
- 50.80mm bolt centre turbo drain flange withM8 x 1.25mm thread size

CompressorSpecifications
Inducer:  98mm
Exducer:  133mm
Extended Tip:  138mm

Turbine Specifications
Inducer:  112mm
Exducer:  102mm

Boosted Turbocharger Replacement Core.

As another way of backing up our excellent Boosted Turbocharger range, we stock replacement core's for all popular Boosted Turbo models. This way if you have a mis-hapthat has damaged either of thewheels or even the internals of the turbocharger you can easily purchase the core and swap it out. These cores are designed to suit Boosted Turbochargers specifically however you may find some crossover on other brands thathave a similar core design.

BOOSTED 98102 Core Specifications

Recommended horsepower rating:  1000-2500HP
Recommended engine displacement:  3.0L to 7.0L

- 360¬? journal bearing
- 7075 billet 7 + 7 compressor wheel
- This is an oil cooled turbocharger
- Must use a-6AN oil feel line to maintaincore temperature (Warranty VOID if not used)
- 1/4" NPT oilfeed fitting (sold separately)or a 38mm 2-bolt oil feed plate with M8 x 1.25mm thread size
- 50.80mm bolt centre turbo drain flange withM8 x 1.25mm thread size

CompressorSpecifications
Inducer:  98mm
Exducer:  133mm
Extended Tip:  138mm

Turbine Specifications
Inducer:  112mm
Exducer:  102mm
