Description

Boosted Turbocharger Replacement Core.

As another way of backing up our excellent Boosted Turbocharger range, we stock replacement core's for all popular Boosted Turbo models. This way if you have a mis-hapthat has damaged either of thewheels or even the internals of the turbocharger you can easily purchase the core and swap it out. These cores are designed to suit Boosted Turbochargers specifically however you may find some crossover on other brands thathave a similar core design.

Specifications

BOOSTED 5047 Core Specifications

Recommended horsepower rating:  275-550HP
Recommended engine displacement:  1.4L to 2.5L

- Dual ceramicball bearing
- Billet aluminium compressor wheel
- Inlet flange gasket, turbo drain gasket and -4AN turbo oil feed fitting with restrictor included in turbo kit. (Warranty VOID if not used)
- M14 x 1.5mm coolant port thread
- 7/16"-24 oil feed fittingthread
- 38mm bolt centreturbo drain flange with M8 x 1.25mm thread size
- M8 x1.25mm 5-bolt turbine outlet flange

Compressor Specifications
Inducer:  50mm
Exducer:  67mm
Extended Tip:  69.64mm

Turbine Specifications
Inducer:  53.9mm
Exducer:  47mm

Boosted Turbocharger Replacement Core.

As another way of backing up our excellent Boosted Turbocharger range, we stock replacement core's for all popular Boosted Turbo models. This way if you have a mis-hapthat has damaged either of thewheels or even the internals of the turbocharger you can easily purchase the core and swap it out. These cores are designed to suit Boosted Turbochargers specifically however you may find some crossover on other brands thathave a similar core design.

BOOSTED 5047 Core Specifications

Recommended horsepower rating:  275-550HP
Recommended engine displacement:  1.4L to 2.5L

- Dual ceramicball bearing
- Billet aluminium compressor wheel
- Inlet flange gasket, turbo drain gasket and -4AN turbo oil feed fitting with restrictor included in turbo kit. (Warranty VOID if not used)
- M14 x 1.5mm coolant port thread
- 7/16"-24 oil feed fittingthread
- 38mm bolt centreturbo drain flange with M8 x 1.25mm thread size
- M8 x1.25mm 5-bolt turbine outlet flange

Compressor Specifications
Inducer:  50mm
Exducer:  67mm
Extended Tip:  69.64mm

Turbine Specifications
Inducer:  53.9mm
Exducer:  47mm
