Description

Raceworks Fuel Pressure Regulators are machined from high grade 6061-T6 Billet aluminium. These regulators are an ideal upgrade to your fuel system whether it be a flow through or dead head system and will support up to 700hp. All regulators come with 1/8" NPT gauge reference ports, compatible with all known fuels and are fully adjustable with a rising rate of 1:1. Brackets and screws supplied.





Specifications

  • 2 x AN-6 Inlets and AN-6 Return. 1/8" NPT Gauge Port. Base Pressure Range of 40-75PSI (2.75-5.2Bar). Boost Referenced (1:1 Ratio). Boost Reference Port is 1/16" NPT. Dimensions are 94mm high, 62mm wide and 60mm deep with no fittings. E85 and PUMP Fuel Safe. Bypass Rate of 550LPH.

Compatibility

  • Universal Part

Raceworks Fuel Pressure Regulators are machined from high grade 6061-T6 Billet aluminium. These regulators are an ideal upgrade to your fuel system whether it be a flow through or dead head system and will support up to 700hp. All regulators come with 1/8" NPT gauge reference ports, compatible with all known fuels and are fully adjustable with a rising rate of 1:1. Brackets and screws supplied.





  • 2 x AN-6 Inlets and AN-6 Return. 1/8" NPT Gauge Port. Base Pressure Range of 40-75PSI (2.75-5.2Bar). Boost Referenced (1:1 Ratio). Boost Reference Port is 1/16" NPT. Dimensions are 94mm high, 62mm wide and 60mm deep with no fittings. E85 and PUMP Fuel Safe. Bypass Rate of 550LPH.
  • Universal Part
