Description

  • Dual Ceramic Ball Bearing System
  • 9 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip Technology
  • Inconel 713c 10 Blade Turbine Wheel
  • Multiple options for turbine housing
  • V-Band Flange kit(s) for the exhaust housing included
  • Max Air Flow rate: ~65 lb/min, rated @ 750 FWHP
  • Compressor Wheel: 58*76mm
  • Turbine Wheel: 60*55mm
  • Compressor Inlet: 3? Hose
  • Compressor Outlet: 2? Hose
  • Turbine Inlet: T3, T4 or 2.5? V-Band
  • Turbine Outlet: 3? V-Band (3.55?OD)
  • Oil Feed: -4 AN connect to the Oil Restrictor
  • Oil Drain: Std T3 Flange
  • Water In/Outlet: M14*1.5

    We highly recommended running water cooling for better durability.

    Specifications

    Compatibility

    • Universal Part
    • Dual Ceramic Ball Bearing System
    • 9 Blade Gen2 Billet Compressor Wheel with Extended Tapered Tip Technology
    • Inconel 713c 10 Blade Turbine Wheel
    • Multiple options for turbine housing
    • V-Band Flange kit(s) for the exhaust housing included
    • Max Air Flow rate: ~65 lb/min, rated @ 750 FWHP
    • Compressor Wheel: 58*76mm
    • Turbine Wheel: 60*55mm
    • Compressor Inlet: 3? Hose
    • Compressor Outlet: 2? Hose
    • Turbine Inlet: T3, T4 or 2.5? V-Band
    • Turbine Outlet: 3? V-Band (3.55?OD)
    • Oil Feed: -4 AN connect to the Oil Restrictor
    • Oil Drain: Std T3 Flange
    • Water In/Outlet: M14*1.5

      We highly recommended running water cooling for better durability.

      • Universal Part
