Description

Corvette owners can now replace their worn out Magna-Pulse distributors with this precision Pro-Billet Tach Drive Distributor. Advantages such as an accurate magnetic pick-up, oversized shaft, vacuum advance and a billet aluminum housing are just a few of the MSD advantages.

Inside the billet housing, a sealed ball bearing and long sintered bushing guide a 0.500" steel shaft for high rpm accuracy. A special reluctor is mounted to this shaft and is responsible for triggering the magnetic pick-up.

An adjustable mechanical advance assembly allows you to get the most performance out of your Vette's engine by custom tailoring a timing curve to fit your application.

The tach drive assembly is compact to clear the firewall and linkage. It can be repositioned easily to fit different applications plus has a grease fitting for lubrication.

Features

  • Same features as the PN 8571 with the addition of a vacuum advance
  • CARB E.O. Approved

Specifications

BrandMSD
C.A.R.B. EO #D-40-39
ColourRed
Distributor TypeMechanical Tach Drive
Emission Code1
Product TypeDistributor
Sale CategoryIgnition
WarrantyLimited 1 Year Warranty

Compatibility

  • 1962 - 1962 Chevrolet Corvette Base 5.3
  • 1963 - 1968 Chevrolet Corvette Base 5.3
  • 1966 - 1969 Chevrolet Corvette Base 7.0
  • 1968 - 1968 Chevrolet Corvette Base 5.4
  • 1969 - 1972 Chevrolet Corvette Base 5.7
  • 1974 - 1974 Chevrolet Corvette Base 5.7
  • 1970 - 1974 Chevrolet Corvette Base 7.4

Corvette owners can now replace their worn out Magna-Pulse distributors with this precision Pro-Billet Tach Drive Distributor. Advantages such as an accurate magnetic pick-up, oversized shaft, vacuum advance and a billet aluminum housing are just a few of the MSD advantages.

Inside the billet housing, a sealed ball bearing and long sintered bushing guide a 0.500" steel shaft for high rpm accuracy. A special reluctor is mounted to this shaft and is responsible for triggering the magnetic pick-up.

An adjustable mechanical advance assembly allows you to get the most performance out of your Vette's engine by custom tailoring a timing curve to fit your application.

The tach drive assembly is compact to clear the firewall and linkage. It can be repositioned easily to fit different applications plus has a grease fitting for lubrication.

Features

  • Same features as the PN 8571 with the addition of a vacuum advance
  • CARB E.O. Approved
BrandMSD
C.A.R.B. EO #D-40-39
ColourRed
Distributor TypeMechanical Tach Drive
Emission Code1
Product TypeDistributor
Sale CategoryIgnition
WarrantyLimited 1 Year Warranty
  • 1962 - 1962 Chevrolet Corvette Base 5.3
  • 1963 - 1968 Chevrolet Corvette Base 5.3
  • 1966 - 1969 Chevrolet Corvette Base 7.0
  • 1968 - 1968 Chevrolet Corvette Base 5.4
  • 1969 - 1972 Chevrolet Corvette Base 5.7
  • 1974 - 1974 Chevrolet Corvette Base 5.7
  • 1970 - 1974 Chevrolet Corvette Base 7.4
