Description

The world famous Red®, Blue® and Black® fuel pumps are the most recognized performance pumps of all time. They have been powering racing legends and street enthusiasts alike since the early 70s. Their time proven rotor/vane design is known to get the job done in an affordable package.

Features

  • Tumble polished billet look
  • Lower housing casting designed for enhanced fuel flow
  • Motor draws only 3 amps current
  • Relay kit P/N 12-753 & 7 1/2 amp fuse recommended
  • Improved design for street/strip applications
  • Not designed for use on aircraft of any type
  • Distinctive “Blue” logo
  • Flows 110 GPH (free flow)
  • Flows 88 GPH at 9 psi
  • Maximum pressure is 14 psi
  • Includes P/N 12-803 fuel pressure regulator
  • Provides constant fuel flow with no pulsation
  • Has externally accessible pressure relief valve (max 14 psi)
  • Rotor/vane pump design is more tolerant of contaminated fuels
  • Weighs only 3 lbs
  • Includes mounting bracket
  • Repair kits are readily available
  • Can be serviced from the pump end
  • Not compatible with alcohol or methanol fuels
  • Use of safety shut-off switch, P/N 12-810, strongly recommended
  • Not designed or recommended for use with fuel injection systems

Specifications

ApplicationUniversal
Bracket ColourSilver
BrandHolley
Emission Code5
Free Flow GPH110
Free Flow LPH416
Fuel Delivery TypeCarburetor
Fuel Sending Unit IncludedNo
Fuel SystemCarbureted
Fuel TypeGasoline
Gasket Or Seal IncludedNo
Grade TypePerformance
Inlet Fitting Thread Size3/8
Inlet Size3/8 inch NPT
Inlet TypeNPT
Internal Or ExternalExternal
MaterialAluminum
Maximum Amperage Draw3
Maximum Flow Rating110
Maximum Pressure14
Motor FinishSilver
Negative GroundYes
Outlet Fitting Thread Size3/8
Outlet Quantity1
Outlet Size3/8 inch NPT
Outlet TypeNPT
Product TypeFuel Pump
Pump Body ColourSilver
Regulator IncludedYes
Sale CategoryAir and Fuel Delivery
Universal Or Specific FitUniversal
Voltage12
WarrantyLimited 90 Day
Wire Quantity2

Compatibility

  • Universal Part

The world famous Red®, Blue® and Black® fuel pumps are the most recognized performance pumps of all time. They have been powering racing legends and street enthusiasts alike since the early 70s. Their time proven rotor/vane design is known to get the job done in an affordable package.

Features

  • Tumble polished billet look
  • Lower housing casting designed for enhanced fuel flow
  • Motor draws only 3 amps current
  • Relay kit P/N 12-753 & 7 1/2 amp fuse recommended
  • Improved design for street/strip applications
  • Not designed for use on aircraft of any type
  • Distinctive “Blue” logo
  • Flows 110 GPH (free flow)
  • Flows 88 GPH at 9 psi
  • Maximum pressure is 14 psi
  • Includes P/N 12-803 fuel pressure regulator
  • Provides constant fuel flow with no pulsation
  • Has externally accessible pressure relief valve (max 14 psi)
  • Rotor/vane pump design is more tolerant of contaminated fuels
  • Weighs only 3 lbs
  • Includes mounting bracket
  • Repair kits are readily available
  • Can be serviced from the pump end
  • Not compatible with alcohol or methanol fuels
  • Use of safety shut-off switch, P/N 12-810, strongly recommended
  • Not designed or recommended for use with fuel injection systems
ApplicationUniversal
Bracket ColourSilver
BrandHolley
Emission Code5
Free Flow GPH110
Free Flow LPH416
Fuel Delivery TypeCarburetor
Fuel Sending Unit IncludedNo
Fuel SystemCarbureted
Fuel TypeGasoline
Gasket Or Seal IncludedNo
Grade TypePerformance
Inlet Fitting Thread Size3/8
Inlet Size3/8 inch NPT
Inlet TypeNPT
Internal Or ExternalExternal
MaterialAluminum
Maximum Amperage Draw3
Maximum Flow Rating110
Maximum Pressure14
Motor FinishSilver
Negative GroundYes
Outlet Fitting Thread Size3/8
Outlet Quantity1
Outlet Size3/8 inch NPT
Outlet TypeNPT
Product TypeFuel Pump
Pump Body ColourSilver
Regulator IncludedYes
Sale CategoryAir and Fuel Delivery
Universal Or Specific FitUniversal
Voltage12
WarrantyLimited 90 Day
Wire Quantity2
  • Universal Part
