Description

Stage 2 -1B Sprung Ceramic Clutch Kits are recommended for motorsport and track applications.

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

This kit includes: (see specifications tab for full list of inclusions)

  • Clutch Disc
  • Pressure Plate

This kit does not include:

  • Concentric Slave Cylinder
  • Flywheel

Note: for vehicles using a conventional external slave cylinder, a release or throw-out bearing is included in kits. For cars using a concentric slave cylinder (CSC), the release bearing is part of the CSC. Changing CSC is recommended when replacing the clutch as it involves removing the gearbox to install.

Where a replacement flywheel or CSC is required, consider an alternate kit listed with our Parts Finder that includes these options.

Specifications

  • Number of Teeth:

    18

  • Hub Profile:

    21,0 x 18T

  • Supplementary Article/Supplementary Info:

    with synthetic grease

  • Clutch Type:

    High-Performance Clutch

  • for flywheel depth [mm]:

    0,5

  • Max. transferable engine torque [Nm]:

    350

  • Friction Lining Outer Diameter [mm]:

    200

  • Flywheel Profile:

    elevated flywheel

  • Friction lining material:

    Ceramic

  • Compatibility

    • 1982 - 1992 > CITROËN > BX > Petrol Engine 16 XB-_ Hatchback 68KW
    • 1986 - 1987 > CITROËN > BX > Petrol Engine 19 XB-_ Hatchback 75KW
    • 1987 - 1994 > CITROËN > BX > Petrol Engine 19 GTi XB-_ Hatchback 88KW
    • 1986 - 1994 > CITROËN > BX > Petrol Engine 19 XB-_ Wagon 75KW
    • 1990 - 1994 > CITROËN > BX > Petrol Engine 19 XB-_ Wagon 88KW
    • 1986 - 1994 > CITROËN > BX > Petrol Engine 19 Cat XB-_ Wagon 75KW
    • 1987 - 1989 > PEUGEOT > 205 > Petrol Engine 1.6 GTI 20A/C Hatchback 76KW
    • 1987 - 1998 > PEUGEOT > 205 > Petrol Engine 1.9 GTI 20A/C Hatchback 94KW
    • 1991 - 1994 > PEUGEOT > 205 > Petrol Engine 1.6 Aut. 20A/C Hatchback 65KW
    • 1987 - 1989 > PEUGEOT > 205 > Petrol Engine 1.9 GTI 20A/C Hatchback 75KW
    • 1987 - 1994 > PEUGEOT > 205 > Petrol Engine 1.9 GTI 20A/C Hatchback 88KW
    • 1987 - 1994 > PEUGEOT > 205 > Petrol Engine 1.9 GTI Cat 20A/C Hatchback 75KW
    • 1990 - 1992 > PEUGEOT > 205 > Petrol Engine 1.6 20A/C Hatchback 66KW
    • 1988 - 1992 > PEUGEOT > 405 > Diesel 1.9 Diesel 15B Sedan 51KW
    • 1988 - 1992 > PEUGEOT > 405 > Diesel 1.9 D 15E Wagon 51KW

    Stage 2 -1B Sprung Ceramic Clutch Kits are recommended for motorsport and track applications.

    The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

    This kit includes: (see specifications tab for full list of inclusions)

    • Clutch Disc
    • Pressure Plate

    This kit does not include:

    • Concentric Slave Cylinder
    • Flywheel

    Note: for vehicles using a conventional external slave cylinder, a release or throw-out bearing is included in kits. For cars using a concentric slave cylinder (CSC), the release bearing is part of the CSC. Changing CSC is recommended when replacing the clutch as it involves removing the gearbox to install.

    Where a replacement flywheel or CSC is required, consider an alternate kit listed with our Parts Finder that includes these options.

  • Number of Teeth:

    18

  • Hub Profile:

    21,0 x 18T

  • Supplementary Article/Supplementary Info:

    with synthetic grease

  • Clutch Type:

    High-Performance Clutch

  • for flywheel depth [mm]:

    0,5

  • Max. transferable engine torque [Nm]:

    350

  • Friction Lining Outer Diameter [mm]:

    200

  • Flywheel Profile:

    elevated flywheel

  • Friction lining material:

    Ceramic

    • 1982 - 1992 > CITROËN > BX > Petrol Engine 16 XB-_ Hatchback 68KW
    • 1986 - 1987 > CITROËN > BX > Petrol Engine 19 XB-_ Hatchback 75KW
    • 1987 - 1994 > CITROËN > BX > Petrol Engine 19 GTi XB-_ Hatchback 88KW
    • 1986 - 1994 > CITROËN > BX > Petrol Engine 19 XB-_ Wagon 75KW
    • 1990 - 1994 > CITROËN > BX > Petrol Engine 19 XB-_ Wagon 88KW
    • 1986 - 1994 > CITROËN > BX > Petrol Engine 19 Cat XB-_ Wagon 75KW
    • 1987 - 1989 > PEUGEOT > 205 > Petrol Engine 1.6 GTI 20A/C Hatchback 76KW
    • 1987 - 1998 > PEUGEOT > 205 > Petrol Engine 1.9 GTI 20A/C Hatchback 94KW
    • 1991 - 1994 > PEUGEOT > 205 > Petrol Engine 1.6 Aut. 20A/C Hatchback 65KW
    • 1987 - 1989 > PEUGEOT > 205 > Petrol Engine 1.9 GTI 20A/C Hatchback 75KW
    • 1987 - 1994 > PEUGEOT > 205 > Petrol Engine 1.9 GTI 20A/C Hatchback 88KW
    • 1987 - 1994 > PEUGEOT > 205 > Petrol Engine 1.9 GTI Cat 20A/C Hatchback 75KW
    • 1990 - 1992 > PEUGEOT > 205 > Petrol Engine 1.6 20A/C Hatchback 66KW
    • 1988 - 1992 > PEUGEOT > 405 > Diesel 1.9 Diesel 15B Sedan 51KW
    • 1988 - 1992 > PEUGEOT > 405 > Diesel 1.9 D 15E Wagon 51KW
