Description

Stage 2R Racing Sprung Ceramic Motorsport upgrades are designed specifically for motorsport applications that require a higher torque capacity than the stage 2 equivalents. Each Stage 2R kit includes an Extra Heavy Duty pressure plate with even higher clamping force and a sprung ceramic friction disc.

These kits are designed specifically for motorsport applications such as circuit, rally, drifting and drag racing.

This kit includes: (see specifications tab for full list of inclusions)

  • Clutch Disc
  • Pressure Plate

This kit does not include:

  • Concentric Slave Cylinder
  • Flywheel

Note: for vehicles using a conventional external slave cylinder, a release or throw-out bearing is included in kits. For cars using a concentric slave cylinder (CSC), the release bearing is part of the CSC. Changing CSC is recommended when replacing the clutch as it involves removing the gearbox to install.

Where a replacement flywheel or CSC is required, consider an alternate kit listed with our Parts Finder that includes these options.

Specifications

  • Number of Teeth:

    22

  • Hub Profile:

    24,5x22T

  • Supplementary Article/Supplementary Info:

    with pilot bearing

  • Supplementary Article/Supplementary Info:

    with synthetic grease

  • Supplementary Article/Supplementary Info:

    for use in motor sport

  • Clutch Type:

    High-Performance Clutch

  • for flywheel depth [mm]:

    8,0

  • Max. transferable engine torque [Nm]:

    660

  • Friction Lining Outer Diameter [mm]:

    215

  • Flywheel Profile:

    recessed flywheel

  • Friction lining material:

    Ceramic

  • Compatibility

    • 1989 - 1993 > MAZDA > MX-5 > Petrol Engine 1.6 (NA6C) NA Convertible 85KW
    • 1975 - 1979 > MAZDA > RX-5 > Wankel 1.1 (CD22S) Coupe 92KW
    • 1972 - 1975 > MAZDA > RX-3 > Wankel 1.1 (S124A) Sedan 82KW
    • 1973 - 1976 > MAZDA > RX-3 > Wankel 1.1 (S124A) Coupe 82KW
    • 1973 - 1975 > MAZDA > RX-4 > Wankel 1.1 (LA22S) Sedan 97KW
    • 1974 - 1978 > MAZDA > RX-4 > Wankel 1.3 (LA23S) Sedan 93KW
    • 1974 - 1978 > MAZDA > RX-4 > Wankel 1.3 (LA23S) Coupe 101KW
    • 1970 - 1976 > MAZDA > RX-2 > Wankel 1.1 (S122A) Coupe 97KW
    • 1970 - 1976 > MAZDA > RX-2 > Wankel 1.1 (S122A) Sedan 97KW

    Stage 2R Racing Sprung Ceramic Motorsport upgrades are designed specifically for motorsport applications that require a higher torque capacity than the stage 2 equivalents. Each Stage 2R kit includes an Extra Heavy Duty pressure plate with even higher clamping force and a sprung ceramic friction disc.

    These kits are designed specifically for motorsport applications such as circuit, rally, drifting and drag racing.

    This kit includes: (see specifications tab for full list of inclusions)

    • Clutch Disc
    • Pressure Plate

    This kit does not include:

    • Concentric Slave Cylinder
    • Flywheel

    Note: for vehicles using a conventional external slave cylinder, a release or throw-out bearing is included in kits. For cars using a concentric slave cylinder (CSC), the release bearing is part of the CSC. Changing CSC is recommended when replacing the clutch as it involves removing the gearbox to install.

    Where a replacement flywheel or CSC is required, consider an alternate kit listed with our Parts Finder that includes these options.

  • Number of Teeth:

    22

  • Hub Profile:

    24,5x22T

  • Supplementary Article/Supplementary Info:

    with pilot bearing

  • Supplementary Article/Supplementary Info:

    with synthetic grease

  • Supplementary Article/Supplementary Info:

    for use in motor sport

  • Clutch Type:

    High-Performance Clutch

  • for flywheel depth [mm]:

    8,0

  • Max. transferable engine torque [Nm]:

    660

  • Friction Lining Outer Diameter [mm]:

    215

  • Flywheel Profile:

    recessed flywheel

  • Friction lining material:

    Ceramic

    • 1989 - 1993 > MAZDA > MX-5 > Petrol Engine 1.6 (NA6C) NA Convertible 85KW
    • 1975 - 1979 > MAZDA > RX-5 > Wankel 1.1 (CD22S) Coupe 92KW
    • 1972 - 1975 > MAZDA > RX-3 > Wankel 1.1 (S124A) Sedan 82KW
    • 1973 - 1976 > MAZDA > RX-3 > Wankel 1.1 (S124A) Coupe 82KW
    • 1973 - 1975 > MAZDA > RX-4 > Wankel 1.1 (LA22S) Sedan 97KW
    • 1974 - 1978 > MAZDA > RX-4 > Wankel 1.3 (LA23S) Sedan 93KW
    • 1974 - 1978 > MAZDA > RX-4 > Wankel 1.3 (LA23S) Coupe 101KW
    • 1970 - 1976 > MAZDA > RX-2 > Wankel 1.1 (S122A) Coupe 97KW
    • 1970 - 1976 > MAZDA > RX-2 > Wankel 1.1 (S122A) Sedan 97KW
