Description

Stage 1A Sprung Organic Clutch Kits are recommended for Street use in vehicles with minor engine modifications.

Sprung organic clutch kits offer exceptional driveability for vehicles used daily but also have performance modifications. The sprung organic disc offers improved dampening which reduces the shock loading on the transmission.

This kit includes: (see specifications tab for full list of inclusions)

  • Clutch Disc
  • Pressure Plate

This kit does not include:

  • Concentric Slave Cylinder
  • Flywheel

Note: for vehicles using a conventional external slave cylinder, a release or throw-out bearing is included in kits. For cars using a concentric slave cylinder (CSC), the release bearing is part of the CSC. Changing CSC is recommended when replacing the clutch as it involves removing the gearbox to install.

Where a replacement flywheel or CSC is required, consider an alternate kit listed with our Parts Finder that includes these options.

Specifications

  • Number of Teeth:

    10

  • Hub Profile:

    27,0x10T

  • Supplementary Article/Supplementary Info:

    with pilot bearing

  • Supplementary Article/Supplementary Info:

    with synthetic grease

  • Max. transferable engine torque [Nm]:

    620

  • Friction Lining Outer Diameter [mm]:

    280

  • Flywheel Profile:

    flat flywheel

  • Friction lining material:

    Organic

  • Compatibility

    • 1970 - 1974 > BOLWELL > NAGARI > Petrol Engine 4.9 NG1 Coupe 157KW
    • 1970 - 1974 > BOLWELL > NAGARI > Petrol Engine 4.9 NG1 Convertible 157KW
    • 1970 - 1972 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.9 V8 302ci ZD Sedan 164KW
    • 1970 - 1972 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 5.8 V8 351ci ZD Sedan 186KW
    • 1972 - 1973 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.9 V8 302ci ZF Sedan 179KW
    • 1973 - 1976 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.9 V8 302ci ZG Sedan 179KW
    • 1979 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XD Sedan 140KW
    • 1979 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 5.8 V8 351ci XD Sedan 149KW
    • 1979 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XD Wagon 140KW
    • 1979 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 5.8 V8 351ci XD Wagon 149KW
    • 1982 - 1983 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XE Wagon 140KW
    • 1982 - 1983 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XE Sedan 140KW
    • 1982 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 5.8 V8 351ci XE Sedan 149KW
    • 1969 - 1970 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XW Wagon 164KW
    • 1970 - 1972 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XY Wagon 165KW
    • 1970 - 1972 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XY Sedan 165KW
    • 1979 - 1982 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XD Ute 140KW
    • 1979 - 1982 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XD Ute 149KW
    • 1969 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XW Sedan 164KW
    • 1970 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT HO Phase 1.5 XW Sedan 224KW
    • 1970 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT HO Phase 2 XW Sedan 225KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XY Sedan 164KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XY Sedan 186KW
    • 1971 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT HO Phase 3 XY Sedan 224KW
    • 1969 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XW Ute 164KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XY Ute 164KW
    • 1979 - 1982 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XD Wagon Van 140KW
    • 1979 - 1982 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XD Wagon Van 149KW
    • 1969 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT XW Sedan 216KW
    • 1971 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT HO Phase 3 XY Sedan 276KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XY Wagon 164KW
    • 1976 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XC Coupe 151KW
    • 1976 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XC Coupe 162KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XA Coupe 179KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XA Coupe 194KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 GT 351ci XA Coupe 224KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XB Coupe 179KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XB Coupe 194KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 GT 351ci XB Coupe 224KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XB Wagon Van 179KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XB Ute 179KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XB Ute 194KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XY Wagon Van 164KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XA Ute 179KW
    • 1976 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XC Ute 151KW
    • 1977 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XC Ute 162KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XA Wagon Van 179KW
    • 1976 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XC Wagon Van 151KW
    • 1977 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XC Wagon Van 162KW
    • 1968 - 1973 > FORD USA > MUSTANG > Petrol Engine 4.1 Convertible 116KW
    • 1968 - 1973 > FORD USA > MUSTANG > Petrol Engine 4.1 Coupe 116KW
    • 1971 - 1971 > FORD USA > MUSTANG > Petrol Engine 4.1 Convertible 106KW
    • 1971 - 1971 > FORD USA > MUSTANG > Petrol Engine 4.1 Coupe 106KW

    Stage 1A Sprung Organic Clutch Kits are recommended for Street use in vehicles with minor engine modifications.

    Sprung organic clutch kits offer exceptional driveability for vehicles used daily but also have performance modifications. The sprung organic disc offers improved dampening which reduces the shock loading on the transmission.

    This kit includes: (see specifications tab for full list of inclusions)

    • Clutch Disc
    • Pressure Plate

    This kit does not include:

    • Concentric Slave Cylinder
    • Flywheel

    Note: for vehicles using a conventional external slave cylinder, a release or throw-out bearing is included in kits. For cars using a concentric slave cylinder (CSC), the release bearing is part of the CSC. Changing CSC is recommended when replacing the clutch as it involves removing the gearbox to install.

    Where a replacement flywheel or CSC is required, consider an alternate kit listed with our Parts Finder that includes these options.

  • Number of Teeth:

    10

  • Hub Profile:

    27,0x10T

  • Supplementary Article/Supplementary Info:

    with pilot bearing

  • Supplementary Article/Supplementary Info:

    with synthetic grease

  • Max. transferable engine torque [Nm]:

    620

  • Friction Lining Outer Diameter [mm]:

    280

  • Flywheel Profile:

    flat flywheel

  • Friction lining material:

    Organic

    • 1970 - 1974 > BOLWELL > NAGARI > Petrol Engine 4.9 NG1 Coupe 157KW
    • 1970 - 1974 > BOLWELL > NAGARI > Petrol Engine 4.9 NG1 Convertible 157KW
    • 1970 - 1972 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.9 V8 302ci ZD Sedan 164KW
    • 1970 - 1972 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 5.8 V8 351ci ZD Sedan 186KW
    • 1972 - 1973 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.9 V8 302ci ZF Sedan 179KW
    • 1973 - 1976 > FORD AUSTRALIA > FAIRLANE > Petrol Engine 4.9 V8 302ci ZG Sedan 179KW
    • 1979 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XD Sedan 140KW
    • 1979 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 5.8 V8 351ci XD Sedan 149KW
    • 1979 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XD Wagon 140KW
    • 1979 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 5.8 V8 351ci XD Wagon 149KW
    • 1982 - 1983 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XE Wagon 140KW
    • 1982 - 1983 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XE Sedan 140KW
    • 1982 - 1982 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 5.8 V8 351ci XE Sedan 149KW
    • 1969 - 1970 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XW Wagon 164KW
    • 1970 - 1972 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XY Wagon 165KW
    • 1970 - 1972 > FORD AUSTRALIA > FAIRMONT > Petrol Engine 4.9 V8 302ci XY Sedan 165KW
    • 1979 - 1982 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XD Ute 140KW
    • 1979 - 1982 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XD Ute 149KW
    • 1969 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XW Sedan 164KW
    • 1970 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT HO Phase 1.5 XW Sedan 224KW
    • 1970 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT HO Phase 2 XW Sedan 225KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XY Sedan 164KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XY Sedan 186KW
    • 1971 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT HO Phase 3 XY Sedan 224KW
    • 1969 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XW Ute 164KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XY Ute 164KW
    • 1979 - 1982 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XD Wagon Van 140KW
    • 1979 - 1982 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XD Wagon Van 149KW
    • 1969 - 1970 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT XW Sedan 216KW
    • 1971 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 GT HO Phase 3 XY Sedan 276KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XY Wagon 164KW
    • 1976 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XC Coupe 151KW
    • 1976 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XC Coupe 162KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XA Coupe 179KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XA Coupe 194KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 GT 351ci XA Coupe 224KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XB Coupe 179KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XB Coupe 194KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 GT 351ci XB Coupe 224KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XB Wagon Van 179KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XB Ute 179KW
    • 1973 - 1976 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XB Ute 194KW
    • 1970 - 1972 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XY Wagon Van 164KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XA Ute 179KW
    • 1976 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XC Ute 151KW
    • 1977 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XC Ute 162KW
    • 1972 - 1973 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XA Wagon Van 179KW
    • 1976 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 4.9 V8 302ci XC Wagon Van 151KW
    • 1977 - 1979 > FORD AUSTRALIA > FALCON > Petrol Engine 5.8 V8 351ci XC Wagon Van 162KW
    • 1968 - 1973 > FORD USA > MUSTANG > Petrol Engine 4.1 Convertible 116KW
    • 1968 - 1973 > FORD USA > MUSTANG > Petrol Engine 4.1 Coupe 116KW
    • 1971 - 1971 > FORD USA > MUSTANG > Petrol Engine 4.1 Convertible 106KW
    • 1971 - 1971 > FORD USA > MUSTANG > Petrol Engine 4.1 Coupe 106KW
