Description

Stage 2 -1B Sprung Ceramic Clutch Kits are recommended for motorsport and track applications.

The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

This kit includes: (see specifications tab for full list of inclusions)

  • Clutch Disc
  • Pressure Plate

This kit does not include:

  • Concentric Slave Cylinder
  • Flywheel

Note: for vehicles using a conventional external slave cylinder, a release or throw-out bearing is included in kits. For cars using a concentric slave cylinder (CSC), the release bearing is part of the CSC. Changing CSC is recommended when replacing the clutch as it involves removing the gearbox to install.

Where a replacement flywheel or CSC is required, consider an alternate kit listed with our Parts Finder that includes these options.

Specifications

  • Number of Teeth:

    24

  • Hub Profile:

    20,5 x 24T

  • Supplementary Article/Supplementary Info:

    with synthetic grease

  • for flywheel depth [mm]:

    24,0

  • Max. transferable engine torque [Nm]:

    310

  • Friction Lining Outer Diameter [mm]:

    215

  • Flywheel Profile:

    recessed flywheel

  • Friction lining material:

    Ceramic

  • Compatibility

    • 1978 - 1981 > ALFA ROMEO > ALFASUD > Petrol Engine 1.5 (902.A1) 902_ Coupe 61KW
    • 1979 - 1983 > ALFA ROMEO > ALFASUD > Petrol Engine 1.5 (902.A5) 902_ Coupe 70KW
    • 1974 - 1984 > ALFA ROMEO > ALFASUD > Petrol Engine 1.2 (901.D0, 901.D1) 901_ Hatchback 46KW
    • 1979 - 1984 > ALFA ROMEO > ALFASUD > Petrol Engine 1.5 ti (901.F1, 901.F4, 901.G1) 901_ Hatchback 61KW
    • 1980 - 1984 > ALFA ROMEO > ALFASUD > Petrol Engine 1.5 ti (901G5A, 901F4D) 901_ Hatchback 70KW
    • 1983 - 1987 > ALFA ROMEO > 33 > Petrol Engine 1.5 (905.A2A) 905_ Hatchback 62KW
    • 1984 - 1989 > ALFA ROMEO > 33 > Petrol Engine 1.5 QV (905.A2N, 905.A2V) 905_ Hatchback 77KW
    • 1984 - 1986 > ALFA ROMEO > 33 > Petrol Engine 1.5 4x4 (905.A2B, 905.A2C) 905_ Wagon 66KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 i.e. (907.A1A) 907_ Hatchback 79KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V (907.A1C) 907_ Hatchback 95KW
    • 1990 - 1992 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V (907.A1C) 907_ Hatchback 97KW
    • 1983 - 1986 > ALFA ROMEO > 33 > Petrol Engine 1.5 (905.A2G) 905_ Hatchback 66KW
    • 1984 - 1986 > ALFA ROMEO > 33 > Petrol Engine 1.5 (905A) 905_ Wagon 66KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V 4x4 (907.A1G) 907_ Hatchback 95KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V 4x4 (907.A1G) 907_ Hatchback 97KW
    • 1986 - 1989 > ALFA ROMEO > 33 > Petrol Engine 1.7 (905A2A) 905_ Hatchback 95KW
    • 1986 - 1990 > ALFA ROMEO > 33 > Petrol Engine 1.7 (905A3) 905_ Hatchback 87KW
    • 1990 - 1992 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V (907.A1B) 907_ Hatchback 101KW
    • 1984 - 1987 > ALFA ROMEO > 33 > Petrol Engine 1.5 4x4 (905B1, 905A2S) 905_ Wagon 70KW
    • 1984 - 1987 > ALFA ROMEO > 33 > Petrol Engine 1.5 (905A) 905_ Wagon 70KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V 4x4 (907A1F) 907_ Hatchback 101KW

    Stage 2 -1B Sprung Ceramic Clutch Kits are recommended for motorsport and track applications.

    The sprung ceramic range of kits have been developed for motorsport applications where a higher heat and torque capacity is required. These discs utilise a sprung hub that helps to reduce shock loading and are commonly used in track cars that retain the factory transmission.

    This kit includes: (see specifications tab for full list of inclusions)

    • Clutch Disc
    • Pressure Plate

    This kit does not include:

    • Concentric Slave Cylinder
    • Flywheel

    Note: for vehicles using a conventional external slave cylinder, a release or throw-out bearing is included in kits. For cars using a concentric slave cylinder (CSC), the release bearing is part of the CSC. Changing CSC is recommended when replacing the clutch as it involves removing the gearbox to install.

    Where a replacement flywheel or CSC is required, consider an alternate kit listed with our Parts Finder that includes these options.

  • Number of Teeth:

    24

  • Hub Profile:

    20,5 x 24T

  • Supplementary Article/Supplementary Info:

    with synthetic grease

  • for flywheel depth [mm]:

    24,0

  • Max. transferable engine torque [Nm]:

    310

  • Friction Lining Outer Diameter [mm]:

    215

  • Flywheel Profile:

    recessed flywheel

  • Friction lining material:

    Ceramic

    • 1978 - 1981 > ALFA ROMEO > ALFASUD > Petrol Engine 1.5 (902.A1) 902_ Coupe 61KW
    • 1979 - 1983 > ALFA ROMEO > ALFASUD > Petrol Engine 1.5 (902.A5) 902_ Coupe 70KW
    • 1974 - 1984 > ALFA ROMEO > ALFASUD > Petrol Engine 1.2 (901.D0, 901.D1) 901_ Hatchback 46KW
    • 1979 - 1984 > ALFA ROMEO > ALFASUD > Petrol Engine 1.5 ti (901.F1, 901.F4, 901.G1) 901_ Hatchback 61KW
    • 1980 - 1984 > ALFA ROMEO > ALFASUD > Petrol Engine 1.5 ti (901G5A, 901F4D) 901_ Hatchback 70KW
    • 1983 - 1987 > ALFA ROMEO > 33 > Petrol Engine 1.5 (905.A2A) 905_ Hatchback 62KW
    • 1984 - 1989 > ALFA ROMEO > 33 > Petrol Engine 1.5 QV (905.A2N, 905.A2V) 905_ Hatchback 77KW
    • 1984 - 1986 > ALFA ROMEO > 33 > Petrol Engine 1.5 4x4 (905.A2B, 905.A2C) 905_ Wagon 66KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 i.e. (907.A1A) 907_ Hatchback 79KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V (907.A1C) 907_ Hatchback 95KW
    • 1990 - 1992 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V (907.A1C) 907_ Hatchback 97KW
    • 1983 - 1986 > ALFA ROMEO > 33 > Petrol Engine 1.5 (905.A2G) 905_ Hatchback 66KW
    • 1984 - 1986 > ALFA ROMEO > 33 > Petrol Engine 1.5 (905A) 905_ Wagon 66KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V 4x4 (907.A1G) 907_ Hatchback 95KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V 4x4 (907.A1G) 907_ Hatchback 97KW
    • 1986 - 1989 > ALFA ROMEO > 33 > Petrol Engine 1.7 (905A2A) 905_ Hatchback 95KW
    • 1986 - 1990 > ALFA ROMEO > 33 > Petrol Engine 1.7 (905A3) 905_ Hatchback 87KW
    • 1990 - 1992 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V (907.A1B) 907_ Hatchback 101KW
    • 1984 - 1987 > ALFA ROMEO > 33 > Petrol Engine 1.5 4x4 (905B1, 905A2S) 905_ Wagon 70KW
    • 1984 - 1987 > ALFA ROMEO > 33 > Petrol Engine 1.5 (905A) 905_ Wagon 70KW
    • 1990 - 1994 > ALFA ROMEO > 33 > Petrol Engine 1.7 16V 4x4 (907A1F) 907_ Hatchback 101KW
