Description

Notes: Designed to fit a 25.4mm sway bar.

Whiteline's sway bar mount bushings not only boasts the latest in bushing material technology but feature a knurled ID specifically designed to retain grease. Backed up by a Limited Lifetime Warranty. Whiteline bushings are made from the latest highest quality synthetic elastomer and designed to synchronize your suspension system for optimal safety, handling, performance, ride quality, longevity and reduced maintenance. They are the most positive link between your vehicles body, springs, struts, arms, bars and shocks.

Features:

  • The latest in material formulation technology boasts resistance to oil, grease, ozone and weathering.
  • Supplied with extreme pressure molybdenum disulphide (LM) based grease for extended life.
  • Designed with the installer in mind by reducing the need of specialised skills, tools and equipment.
  • This kit is covered by a limited lifetime warranty including parts and labour.
  • Install guide included providing detailed instructions on how to install your new purchase .

Specifications

Bush Type 5 5
Bush Qty 1 1
OD (A) 52.1 mm 52.1 mm
ID (B) 25.4 mm 25.4 mm
L (C) 53.9 mm 53.9 mm
FL (D)
FLOD (E)
C/Tube QTY
C/Tube Size
Similar Bushing Size







Bush Image

What's Included

  • 2 Bushings
  • Install Guide
  • Grease

Compatibility

  • 2000-2007 TOYOTA ALTIS, E120, E130
  • 2006-2012 TOYOTA BLADE, E154, 156
  • 2000-2007 TOYOTA COROLLA, E120, E130
  • 2007-2012 TOYOTA COROLLA, E140, E150
  • 2012-2019 TOYOTA COROLLA, E160, E170, E180
  • 2005-2012 TOYOTA RAV 4, XA30
  • 2012-2018 TOYOTA RAV 4, XA40

Notes: Designed to fit a 25.4mm sway bar.

Whiteline's sway bar mount bushings not only boasts the latest in bushing material technology but feature a knurled ID specifically designed to retain grease. Backed up by a Limited Lifetime Warranty. Whiteline bushings are made from the latest highest quality synthetic elastomer and designed to synchronize your suspension system for optimal safety, handling, performance, ride quality, longevity and reduced maintenance. They are the most positive link between your vehicles body, springs, struts, arms, bars and shocks.

Features:

  • The latest in material formulation technology boasts resistance to oil, grease, ozone and weathering.
  • Supplied with extreme pressure molybdenum disulphide (LM) based grease for extended life.
  • Designed with the installer in mind by reducing the need of specialised skills, tools and equipment.
  • This kit is covered by a limited lifetime warranty including parts and labour.
  • Install guide included providing detailed instructions on how to install your new purchase .
Bush Type 5 5
Bush Qty 1 1
OD (A) 52.1 mm 52.1 mm
ID (B) 25.4 mm 25.4 mm
L (C) 53.9 mm 53.9 mm
FL (D)
FLOD (E)
C/Tube QTY
C/Tube Size
Similar Bushing Size







Bush Image

  • 2 Bushings
  • Install Guide
  • Grease
  • 2000-2007 TOYOTA ALTIS, E120, E130
  • 2006-2012 TOYOTA BLADE, E154, 156
  • 2000-2007 TOYOTA COROLLA, E120, E130
  • 2007-2012 TOYOTA COROLLA, E140, E150
  • 2012-2019 TOYOTA COROLLA, E160, E170, E180
  • 2005-2012 TOYOTA RAV 4, XA30
  • 2012-2018 TOYOTA RAV 4, XA40
