Description

Easy suspension tuning is in your hands. S.Tech was made so that everyone can enjoy sports driving. Based on OE specification so that the installation is easy. Full compliance with car inspection. Great styling, plus more fun to drive. The highest quality all brought to you at great prices. Now comes in two types to choose from.

Comforms to Vehicle Safety Regulation (in Japan)
With these new springs, we have been able to maintain the 90mm road clearance legislated in the new safety regulations.

Line Up
Available for a wide array of vehicle models. The best applicable setting to satisfy drivers, either for good appearance or for sport driving.

Cost Efficient
Easy suspension tuning for everyone. Under thorough cost management and improvement of the production line, S.TECH is offered at a very affordable price, even with the use of high-tensile materials with over 200kgf/mm2 (some exceptions).

Note: Image is only a representation of the coilovers. TEIN doesn't have vehicle specific images. Your coilover will be specific to your vehicle. If you have any questions about this kit, please contact us.

Specifications

              SPRING RATE
(kgf/mm)
RIDE HEIGHT
CHANGE(mm)

MAKE MODEL YEAR NOTE CHASSIS DISPLACEMENT DRIVE_SYSTEM Ft Rr Ft Rr REMARKS
SUBARU IMPREZA 2008+ WRX STI (5DR) GRB 2000 AWD 4.5 3.9 -25 -20 WRX STI. RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2008-2014 WRX STI (5DR) GRF 2500 AWD 4.5 3.9 -25 -20 RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2009-2014 WRX STI (5DR) GRF 2500 AWD 4.5 3.9 -25 -20 WRX STI. RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2010+ WRX STI (4DR) GVB 2000 AWD 4.5 3.9 -25 -15 WRX STI SEDAN. RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2010+ WRX STI (4DR) GVF 2500 AWD 4.5 3.9 -25 -15 RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2011-2014 WRX STI (4DR) GVF 2500 AWD 4.5 3.9 -27 -11 RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.

Compatibility

  • 2008+ SUBARU IMPREZA GRB WRX STI (5DR)
  • 2008-2014 SUBARU IMPREZA GRF WRX STI (5DR)
  • 2009-2014 SUBARU IMPREZA GRF WRX STI (5DR)
  • 2010+ SUBARU IMPREZA GVB WRX STI (4DR)
  • 2010+ SUBARU IMPREZA GVF WRX STI (4DR)
  • 2011-2014 SUBARU IMPREZA GVF WRX STI (4DR)

Easy suspension tuning is in your hands. S.Tech was made so that everyone can enjoy sports driving. Based on OE specification so that the installation is easy. Full compliance with car inspection. Great styling, plus more fun to drive. The highest quality all brought to you at great prices. Now comes in two types to choose from.

Comforms to Vehicle Safety Regulation (in Japan)
With these new springs, we have been able to maintain the 90mm road clearance legislated in the new safety regulations.

Line Up
Available for a wide array of vehicle models. The best applicable setting to satisfy drivers, either for good appearance or for sport driving.

Cost Efficient
Easy suspension tuning for everyone. Under thorough cost management and improvement of the production line, S.TECH is offered at a very affordable price, even with the use of high-tensile materials with over 200kgf/mm2 (some exceptions).

Note: Image is only a representation of the coilovers. TEIN doesn't have vehicle specific images. Your coilover will be specific to your vehicle. If you have any questions about this kit, please contact us.

              SPRING RATE
(kgf/mm)
RIDE HEIGHT
CHANGE(mm)

MAKE MODEL YEAR NOTE CHASSIS DISPLACEMENT DRIVE_SYSTEM Ft Rr Ft Rr REMARKS
SUBARU IMPREZA 2008+ WRX STI (5DR) GRB 2000 AWD 4.5 3.9 -25 -20 WRX STI. RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2008-2014 WRX STI (5DR) GRF 2500 AWD 4.5 3.9 -25 -20 RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2009-2014 WRX STI (5DR) GRF 2500 AWD 4.5 3.9 -25 -20 WRX STI. RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2010+ WRX STI (4DR) GVB 2000 AWD 4.5 3.9 -25 -15 WRX STI SEDAN. RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2010+ WRX STI (4DR) GVF 2500 AWD 4.5 3.9 -25 -15 RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
SUBARU IMPREZA 2011-2014 WRX STI (4DR) GVF 2500 AWD 4.5 3.9 -27 -11 RR: CUT BUMP RUBBER AT 35MM FROM THE BOTTOM AND USE THE UPPER PORTION.
  • 2008+ SUBARU IMPREZA GRB WRX STI (5DR)
  • 2008-2014 SUBARU IMPREZA GRF WRX STI (5DR)
  • 2009-2014 SUBARU IMPREZA GRF WRX STI (5DR)
  • 2010+ SUBARU IMPREZA GVB WRX STI (4DR)
  • 2010+ SUBARU IMPREZA GVF WRX STI (4DR)
  • 2011-2014 SUBARU IMPREZA GVF WRX STI (4DR)
