Superior Engineering has designed a high-clearance U-bolt plate to replace your original bulky U-bolt plates.

Made from the highest quality materials and now featuring integrated side skirts for extra support to limit twisting of movement of the leaf pack under the diff.

Our side skirts are not only welded in place but secured with the u_bolts as well.

The low profile design gives you added ground clearance without fitting bigger rubber.

We integrate the shock mount into the u-bolt plate allowing the shocks to bolt on with no welding or cutting needed.

Features

• Bolt in design
• Increased strength over OE design
• maintains the maximum ground clearance
• 100% Australian made
• powder coated finish
• integrated shock mounts

NOTE: These are only suitable for use up to factory GVM, vehicles with upgraded GVMs should use the High Clearance Billet Steel U-bolt plates.

NOTE: Due to the relocation of the Lower shock mount, please use a 1 Inch shorter than required rear shock. e.g. with a 3" lift use a 2" lift rear shock.

NOTE: This item is not suitable for fitment with some aftermarket sway bars, please ensure there is sufficient clearance before ordering

NOTE: Not suitable for 60 Series with Factory Diff Locker.

NOTE: For fitment with Airbags, Please see the Superior Lower Airbag Mount in the related products below.

NOTE: Spring pack thickness approx. 55mm minimum.

Sold as a pair.
