Description

ALTA Rear Control Arms directly replace your rear lateral links. The solid design of the ALTA control arms improve traction and handling. As well as giving you far greater control over camber and toe settings on your MINI. Once installed, ALTA control arms are adjustable for fine tuning of camber and toe without having to remove and install the linkage. Simply loosen the adjustment lock nuts and twist the center section to the exact setting you desire. These are easily installed when adding other suspension products like springs, coilovers or swaybars.

The ALTA Rear Control Arms are CNC machined from 6061 aluminum rod and then heavily texture powder coated for corrosion resistance as well as adding some color to your otherwise boring undercarriage. They feature Teflon-lined spherical rod ends for a solid connection, greater articulation and prevent dynamic alignment changes that occur with the rubber bushings found in the OEM control arms.

The ALTA Performance Control arms use an aircraft quality, spherical bearing type of rod end. This solid type connection still allows for smooth and precise movement of the control arm through a far larger range of articulation. Our rod ends use injected Nylon around the center of the ball to keep the ball joint quiet as the part ages.

Two sets of arms can be purchased to replace both sets of upper and lower control arms. Further increasing rear end adjustment, removing even more deflection from the OEM rubber bushings and reducing even more weight from your MINI. Please note on models with Xenon style headlamps the installer will have to modify the mounting for the leveling sensor. Contact your ALTA dealer or our Tech Dept for additional details.

Specifications

Rod Construction 6061 Aluminum Bar Stock
Rod Finish Wrinkle red powder coat
Rod End Nylon lined spherical bearings
Spacers Machined Aluminum
Approximate Camber Adjustment 0 to -4
Approximate Track Adjustment + or -2

What's Included

  • 1 x Paid of Alta Control Arms

  • Mounting hardware

  • Instructions

  • Stickers

Compatibility

  • All Mini's (excluding Countryman/Paceman)

ALTA Rear Control Arms directly replace your rear lateral links. The solid design of the ALTA control arms improve traction and handling. As well as giving you far greater control over camber and toe settings on your MINI. Once installed, ALTA control arms are adjustable for fine tuning of camber and toe without having to remove and install the linkage. Simply loosen the adjustment lock nuts and twist the center section to the exact setting you desire. These are easily installed when adding other suspension products like springs, coilovers or swaybars.

The ALTA Rear Control Arms are CNC machined from 6061 aluminum rod and then heavily texture powder coated for corrosion resistance as well as adding some color to your otherwise boring undercarriage. They feature Teflon-lined spherical rod ends for a solid connection, greater articulation and prevent dynamic alignment changes that occur with the rubber bushings found in the OEM control arms.

The ALTA Performance Control arms use an aircraft quality, spherical bearing type of rod end. This solid type connection still allows for smooth and precise movement of the control arm through a far larger range of articulation. Our rod ends use injected Nylon around the center of the ball to keep the ball joint quiet as the part ages.

Two sets of arms can be purchased to replace both sets of upper and lower control arms. Further increasing rear end adjustment, removing even more deflection from the OEM rubber bushings and reducing even more weight from your MINI. Please note on models with Xenon style headlamps the installer will have to modify the mounting for the leveling sensor. Contact your ALTA dealer or our Tech Dept for additional details.

Rod Construction 6061 Aluminum Bar Stock
Rod Finish Wrinkle red powder coat
Rod End Nylon lined spherical bearings
Spacers Machined Aluminum
Approximate Camber Adjustment 0 to -4
Approximate Track Adjustment + or -2
  • 1 x Paid of Alta Control Arms

  • Mounting hardware

  • Instructions

  • Stickers

  • All Mini's (excluding Countryman/Paceman)
